凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (9-06) - HYDRAULIC THREADER KIT (FLOW CONTROL), (HK50574 HYDRAULIC Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
386 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
1714625
|
[2] |
HOSE
|
CAS
- hydraulic
|
| 2. |
722470
|
[3] |
MOUNTING CLIP
|
CAS
TIE - cable Superseded by part number: 529070
|
| 3. |
7791767
|
[2] |
ELBOW
|
CAS
90 deg. ELBOW (includes item 9) Superseded by part number: 87329788
|
| 4. |
700709807
|
[2] |
HYDRAULIC HOSE,9.65 mm ID x 1925.00 mm, SAE 100R2
|
L
9.65 mm ID x 1925.00 mm, SAE 100R2
|
| 5. |
218-5053
|
[1] |
HYD CONNECTOR,7/16" - 20 JIC x 7/16" - 20 ORB
|
CAS
(includes Ref. 8) 7/16"-20, 37º x 7/16"-20, O-Ring Superseded by part number: 265235
|
| 6. |
700707258
|
[1] |
GOVERNOR
|
IH
REGULATOR - flow, hydraulic
|
| 7. |
6260244
|
[2] |
SPACER
|
HFI
|
| 8. |
7040397
|
[2] |
O-RING
|
IH
Superseded by part number: 165202
|
| 9. |
279706
|
[2] |
O-RING
|
PA
|
| . . |
7773997
|
[2] |
BOLT
|
CAS
5/16-18 x 3-1/4 C Superseded by part number: 280275
|
| . . |
704015
|
[2] |
NUT,5/16"-18, G5
|
CAS
5/16-18 H Superseded by part number: 425-105, 425-105, 9635082
|
| . . |
705020
|
[2] |
LOCK WASHER
|
CAS
5/16" Superseded by part number: 492-11031, 492-11031, NLS
|
