凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (9-16) - RAMP KIT, (HK50586 RAMP KIT COMPLETE) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
993 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700125953
|
[1] |
RAMP
|
HFI
WA
|
| 2. |
700125960
|
[1] |
SHAFT
|
HFI
ARM
|
| 3. |
7701014
|
[1] |
SPECIAL BOLT,Hex, 1/2" - 13 x 2 1/2", Gr 5
|
HFI
BOLT - special Superseded by part number: 113-419
|
| 4. |
700125964
|
[1] |
MOUNTING PARTS
|
HFI
BRACKET
|
| 5. |
7895642
|
[1] |
TINE
|
L
SPRING
|
| . . |
701888
|
[1] |
BOLT,Hex, 3/8" - 16 x 2 1/4", Gr 5
|
CAS
3/8-16 x 2-1/4 C Superseded by part number: 87791064, 87791064, 87936
|
| . . |
703223
|
[2] |
BOLT,Hex, 1/2" - 13 x 4 1/2", Gr 5
|
CAS
1/2-13 x 4-1/2 C Superseded by part number: 87996
|
| . . |
700047
|
[1] |
BOLT
|
CAS
3/8-16 x 1 RHSNB Superseded by part number: 80280503
|
| . . |
231-5348
|
[2] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN Superseded by part number: 86521610
|
| . . |
704734
|
[1] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN Superseded by part number: 86521609
|
| . . |
704023
|
[1] |
NUT,3/8"-16, G5
|
CAS
3/8-16 H Superseded by part number: 280136
|
| . . |
704031
|
[2] |
NUT
|
NNA
1/2-13 H Superseded by part number: 425-108, 425-108, NLS
|
| . . |
705038
|
[1] |
CONTROL VALVE
|
CAS
3/8" Superseded by part number: 492-11038
|
