凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (9-18) - ELECTRIC THREADER KIT (PAGES 9-18 THRU 9-20), (HK50581 Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
497 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700710552
|
[1] |
HARNESS
|
CAS
- wiring
|
| 2. |
700122491
|
[1] |
CHANNEL
|
HFI
|
| 3. |
701953
|
[2] |
SELF-TAP SCREW
|
CAS
5/16-18 x 3/4 HWHTCTS Superseded by part number: 172463
|
| 4. |
700122489
|
[1] |
SHIELD
|
HFI
|
| 5. |
772525
|
[4] |
WASHER
|
NNA
5/16-18 x 1/2 HWHTCTS Superseded by part number: 280-5488, 280-5488, 40923S8
|
| 6. |
705541
|
[5] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 7. |
704056
|
[1] |
NUT
|
CAS
1/2-13 HEX JAM NUT Superseded by part number: 86632558
|
| 8. |
62174
|
[1] |
PIN
|
CAS
5/32 x 1 COTTER PIN Superseded by part number: 83903970
|
| 9. |
700703665
|
[1] |
ACTUATOR
|
IH
- electric
|
| 10. |
700125949
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT WA (LATER MODELS)
|
| 11. |
700122486
|
[1] |
MOUNTING PARTS
|
HFI
MOUNT WA (EARLIER MODELS)
|
| . . |
70922526
|
[1] |
SCREW
|
CMI
1/2-13 x 2-1/2 C Superseded by part number: 20987
|
| . . |
7700156
|
[1] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 x 1-1/2 RHSNB Superseded by part number: 280420
|
| . . |
704015
|
[2] |
NUT,5/16"-18, G5
|
CAS
1/2-13 H Superseded by part number: 425-105, 425-105, 9635082
|
| . . |
80679
|
[2] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
