凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (2-02) - IMPLEMENT DRIVELINE ASSEMBLY (WALTERSHIED) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
791 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700709363
|
[1] |
REAR PTO ASSY
|
CAS
IMPLEMENT HALF ASSEMBLY
|
| 2. |
700709362
|
[1] |
FRONT PTO ASSY
|
CAS
TRACTOR HALF ASSEMBLY (540 RPM)
|
| 3. |
753772
|
[2] |
KIT
|
CAS
JOURNAL REPAIR KIT Superseded by part number: 84355319
|
| 4. |
700709365
|
[1] |
SHIELD
|
CAS
- inner, plastic
|
| 5. |
700708364
|
[1] |
KIT
|
CAS
PIN KIT - quick disconnect Superseded by part number: 237924A1
|
| 6. |
700708365
|
[1] |
YOKE
|
CAS
- tractor, 540 RPM Superseded by part number: 568100R93
|
| 7. |
7813785
|
[1] |
SHAFT
|
CAS
YOKE WITH SHAFT
|
| 8. |
700709007
|
[4] |
CLIP
|
CAS
BEARING - shield
|
| 9. |
700709364
|
[1] |
SHIELD
|
CAS
- outer, plastic
|
| 10. |
7813843
|
[1] |
YOKE
|
IH
YOKE - clamp
|
| 11. |
7813827
|
[1] |
FORK
|
CAS
YOKE WITH TUBE
|
