现代零件查询HDF20/25/30-5 STEERING CYLINDEREPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
565 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31FA-09000
|
[1] |
STEER CYLINDER ASSY
|
|
| 1. |
31Y3-09410
|
[1] |
TUBE ASSY
|
|
| 2. |
31Y3-09450
|
[1] |
ROD ASSY
|
|
| 3. |
31Y3-03820
|
[2] |
GLAND
|
|
| 4. |
S731-050020
|
[2] |
BUSHING
|
|
| K5. |
Y200-050011
|
[2] |
SEAL-ROD
|
|
| K6. |
Y180-050020
|
[2] |
RING-BACK UP
|
|
| K7. |
Y110-050011
|
[2] |
WIPER-DUST
|
|
| 8. |
Y190-062000
|
[2] |
RING-SNAP
|
|
| K9. |
S632-070004
|
[2] |
O-RING
|
|
| K10. |
S632-075001
|
[2] |
O-RING
|
|
| K11. |
Y430-075000
|
[1] |
PISTON-SEAL
|
|
| 12. |
31YC-19230
|
[2] |
BUSH
|
|
| K . |
31Y3-01420
|
[1] |
SEAL KIT(5-7,9-11)
|
|
