凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (4-08) - ACTUATOR ASSEMBLY (700703665 ACTUATOR ASSEMBLY COMPLETE) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
621 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700703665
|
[1] |
ACTUATOR
|
IH
ASSEMBLY COMPLETE
|
| 2. |
700704872
|
[1] |
JACK SCREW
|
HFI
DRIVE SCREW ASSEMBLY
|
| 3. |
700704870
|
[1] |
COVER
|
HFI
- tube
|
| 4. |
700704869
|
[1] |
HOUSING
|
HFI
- front
|
| 5. |
700704873
|
[1] |
CLUTCH ASSEMBLY
|
HFI
|
| 6. |
700704854
|
[1] |
HOUSING
|
HFI
- rear
|
| 7. |
700704861
|
[1] |
GEAR
|
HFI
- intermediate Superseded by part number: 1281484C1
|
| 8. |
700704871
|
[1] |
MOTOR, ELECTRIC
|
HFI
MOTOR - electric
|
| 9. |
700704856
|
[1] |
SEAL KIT
|
HFI
- seal repair, includes items on art marked with an asterisk Superseded by part number: 1281489C1
|
