神钢零件查询(6D14) - MITSUBISHI DIESEL ENGINE - K904C, K907B, K907C & YS750-2 (1/77-12/06) (01-021) - BREATHER & OIL FILLER Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
277 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME031999 | [1] | BREATHER | KOBBREATHER |
| 2. | VAMF520404 | [1] | O-RING | KOBO-RING 40 |
| 3. | VAME031953 | [1] | HOSE | KOBHOSE,RUBBER (FOR M0,M1,M2,M3 ONLY) |
| 3. | VAME030916 | [1] | HOSE,RUBBER (FOR M4,M5 ONLY) | |
| 4. | VA3184393101 | [1] | PIPE | KOBPIPE,BREATHER (FOR M0,M1,M2,M3 ONLY) |
| 4. | VAME030914 | [1] | PIPE,BREATHER (FOR M4,M5 ONLY) | |
| 5. | VAME039196 | [1] | HOSE | KOBHOSE,BREATHER (FOR M0,M5 ONLY) |
| 5. | VAME039198 | [1] | HOSE,BREATHER (FOR M1 ONLY) | |
| 5. | VAME039197 | [1] | HOSE | KOBHOSE,BREATHER (FOR M2 ONLY) |
| 5. | VAME039199 | [1] | FLEXIBLE HOSE | KOBHOSE,BREATHER (FOR M3 ONLY) |
| 6. | VAMH021291 | [3] | CLAMP | KOBCLAMP 40 (FOR M0,M1,M2,M3,M5 ONLY) |
| 7. | VAMF434104 | [1] | NUT | KOBNUT,FLANGE 8 |
| . . | VAMF450005 | [1] | WASHER | KOBWASHER,PLAIN 8 |
