凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (4-10) - ELECTRICAL HARNESS SERVICE PARTS Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
500 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700708756
|
[1] |
CLAMP
|
CAS
- cable (shell size 17) Superseded by part number: 84471900
|
| 2. |
700707012
|
[1] |
TERMINAL CONNECTOR
|
CAS
TOOL - connector repair Superseded by part number: 1964525C1
|
| 3. |
700707013
|
[1] |
TOOL
|
CAS
- connector repair Superseded by part number: CAS1631
|
| 4. |
700707014
|
[1] |
TERMINAL CONNECTOR
|
CAS
TOOL - connector repair Superseded by part number: 1964864C1
|
| 5. |
700708761
|
[1] |
ELEC CONNECTOR,Female
|
IH
CONNECTOR - Female Superseded by part number: 87692855
|
| 6. |
700710659
|
[1] |
CONTACT HOUSING
|
CAS
RECEPTACLE Superseded by part number: 225362C1
|
| 7. |
700709705
|
[1] |
WIRE CONNECTOR
|
CAS
PLUG - standard sex connector Superseded by part number: 87675194
|
| 8. |
700708760
|
[1] |
ELEC. TERMINAL PIN,18 - 20 SAE
|
IH
- sleeve Superseded by part number: 225123C1
|
| 9. |
700710621
|
[1] |
CONTACT HOUSING,Male, Pole
|
CAS
- male
|
| 10. |
700708758
|
[1] |
TERMINAL
|
CAS
SOCKET - female
|
| 11. |
700708757
|
[1] |
ELEC. TERMINAL PIN,18 - 16 SAE
|
CAS
PIN
|
| 12. |
700709234
|
[1] |
CONNECTION,ELECTRIC
|
CAS
RECEPTACLE
|
| 13. |
700710620
|
[1] |
TERMINAL
|
CAS
CONTACT - female
|
| 14. |
700709232
|
[1] |
POWER SOCKET
|
CAS
PLUG
|
| 15. |
700707819
|
[1] |
LOCKING RING
|
CAS
RING - coupling Superseded by part number: 86594691
|
| 16. |
700707817
|
[1] |
RING
|
CAS
- coupling Superseded by part number: 225426C1
|
| 17. |
700709233
|
[1] |
CLAMP
|
CAS
- cable (shell size 11) Superseded by part number: 247725A1
|
