沃尔沃零件查询4400 Radiator4400 NoneNoneNoneAutodata Volvo online
广数供应链运营团队, 14 02月, 2025，浏览：
528 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 5. |
VOE13960141
|
[0008] |
Washer
|
|
| 6. |
VOE955782
|
[0002] |
Hexagon nut
|
|
| 7. |
|
[0001] |
Attaching plate
|
|
| 8. |
|
[0001] |
Rubber moulding
|
|
| 9. |
|
[0001] |
Attaching plate
|
|
| 1. |
VOE4775213
|
[0001] |
Radiator
|
|
| 10. |
|
[0001] |
Retainer
|
H
|
| |
|
[0001] |
Retainer
|
V
|
| 11. |
|
[0002] |
Rubber moulding
|
|
| 12. |
|
[0002] |
Attaching plate
|
|
| 13. |
VOE787653
|
[0002] |
Rubber bushing
|
|
| 14. |
|
[0001] |
Attaching plate
|
|
| 15. |
|
[0001] |
Rubber moulding
|
|
| 16. |
|
[0001] |
Attaching plate
|
|
| 17. |
|
[0008] |
Anchorage
|
|
| 18. |
VOE4939236
|
[0006] |
Retainer
|
|
| 2. |
|
[0002] |
Attaching plate
|
|
| 19. |
VOE4898123
|
[0002] |
Retainer
|
|
| 20. |
VOE13955294
|
[0016] |
Screw
|
|
| 21. |
VOE13960141
|
[0016] |
Washer
|
|
| 22. |
VOE955297
|
[0013] |
Hexagon screw
|
|
| 23. |
VOE13960141
|
[0015] |
Washer
|
|
| 24. |
VOE955782
|
[0010] |
Hexagon nut
|
|
| 3. |
|
[0002] |
Anchorage
|
|
| 4. |
VOE13955294
|
[0006] |
Screw
|
|
