现代零件查询HDF20/25/30-5 DRIVE AXLE(WET)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
1003 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| N . |
81FG-30202
|
[1] |
DRIVE AXLE ASSY-WET
|
|
| N1. |
XKBT-00102
|
[1] |
AXLE HOUSING
|
|
| N2. |
FAC0314020
|
[1] |
CAP
|
|
| N3. |
XKBT-00103
|
[1] |
PLUG
|
|
| N4. |
XKBT-00104
|
[2] |
SCREW-BLEEDER
|
|
| N5. |
XKBT-00105
|
[2] |
FITTING
|
|
| N6. |
XKBT-00106
|
[4] |
SEAL-BRAKE
|
|
| N7. |
FAC0314030
|
[1] |
PLUG
|
|
| N8. |
FAC0314040
|
[1] |
GASKET
|
|
| N9. |
FAC8800170
|
[6] |
PIN-DOWEL
|
|
| N10. |
FAC0314050
|
[1] |
GASKET
|
|
| N11. |
XKBT-00107
|
[13] |
BOLT
|
|
| N12. |
XKBT-00108
|
[13] |
SPRING WASHER
|
|
| N13. |
XKBT-00109
|
[2] |
PARKING LEVER
|
|
| N14. |
XKBT-00110
|
[4] |
SNAP RING
|
|
| N15. |
XKBT-00111
|
[2] |
CAM SHAFT
|
|
| N16. |
XKBT-00112
|
[4] |
COLLAR
|
|
| N17. |
XKBT-00113
|
[4] |
NEDDLE R/BEARING
|
|
| N18. |
XKBT-00114
|
[2] |
ROLLER
|
|
| N19. |
XKBT-00115
|
[2] |
P/WASHER
|
|
| N20. |
XKBT-00116
|
[2] |
SNAP RING
|
|
| N21. |
XKBT-00117
|
[2] |
SQUARE RING
|
|
| N22. |
XKBT-00118
|
[2] |
SQUARE RING
|
|
| N23. |
XKBT-00119
|
[2] |
ACTUATOR
|
|
| N24. |
XKBT-00120
|
[8] |
SPRING
|
|
| N25. |
XKBT-00121
|
[8] |
BOLT
|
|
| N26. |
XKBT-00122
|
[2] |
PISTON
|
|
| N27. |
XKBT-00123
|
[2] |
SNAP RING
|
|
| N28. |
XKBT-00124
|
[8] |
DISC
|
|
| N28. |
XKBT-00513
|
[8] |
COVER-HUB
|
|
| N28. |
XKBT-00124
|
[8] |
DISC
|
|
| N28. |
XKBT-00513
|
[8] |
COVER-HUB
|
|
| N28. |
XKBT-00124
|
[8] |
DISC
|
|
| N28. |
XKBT-00513
|
[8] |
COVER-HUB
|
|
| N29. |
XKBT-00125
|
[10] |
PLATE
|
|
| N29. |
XKBT-00512
|
[10] |
PLATE
|
|
| N29. |
XKBT-00125
|
[10] |
PLATE
|
|
| N29. |
XKBT-00512
|
[10] |
PLATE
|
|
| N29. |
XKBT-00125
|
[10] |
PLATE
|
|
| N29. |
XKBT-00512
|
[10] |
PLATE
|
|
| N30. |
XKBT-00126
|
[2] |
COLLAR-SPLINE
|
|
| N31. |
XKBT-00127
|
[2] |
SPINDLE-LH
|
|
| N31. |
XKBT-00128
|
[2] |
SPINDLE-RH
|
|
| N32. |
XKBT-00129
|
[2] |
BOLT
|
|
| N33. |
XKBT-00130
|
[30] |
BOLT
|
|
| N34. |
XKBT-00131
|
[2] |
OIL SEAL
|
|
| N35. |
XKBT-00132
|
[2] |
TAPER ROLLER BEARING
|
|
| N36. |
XKBT-00133
|
[2] |
WHEEL HUB
|
|
| N37. |
XKBT-00134
|
[12] |
STUD BOLT
|
|
| N38. |
XKBT-00135
|
[2] |
TAPER ROLLER BEARING
|
|
| N39. |
XKBT-00136
|
[2] |
PLATE
|
|
| N40. |
XKBT-00137
|
[2] |
NUT
|
|
| N41. |
XKBT-00138
|
[2] |
OIL SEAL
|
|
| N42. |
XKBT-00139
|
[2] |
BOLT
|
|
| N43. |
XKBT-00140
|
[2] |
DRIVE SHAFT
|
|
| N44. |
XKBT-00108
|
[16] |
SPRING WASHER
|
|
| N45. |
XKBT-00141
|
[16] |
BOLT
|
|
| N51. |
FAC0314100
|
[12] |
NUT-HEX
|
|
| N. |
@
|
[AR] |
NOT SUPPLIED PARTS
|
|
