| 1. |
8046658
|
[1] |
TEE
|
CAS
- adapter (includes item 4) Superseded by part number: 86513020
|
| 2. |
700120632
|
[1] |
HINGE
|
HFI
WA - shield
|
| 3. |
700120631
|
[1] |
PLATE
|
HFI
- support, cylinder
|
| 4. |
863498
|
[2] |
CLEVIS PIN
|
CAS
5/8 x 3-1/2 CLEVIS PIN
|
| 5. |
738468
|
[4] |
O-RING
|
IH
|
| 6. |
700120638
|
[1] |
SUPPORT
|
HFI
- hose
|
| 7. |
700709156
|
[2] |
CYLINDER
|
CAS
- hydraulic (S.N. CFH0012001 thru CFH0012869) Superseded by part number: 700712074
|
| . . |
700712074
|
[2] |
CYLINDER
|
CAS
- hydraulic (S.N. CFH0012870 and later)
|
| 8. |
7872864
|
[2] |
HOSE ASSY.
|
HFI
HOSE - hydraulic
|
| 9. |
80702
|
[2] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
3/8 HARDENED PLAIN WASHER
|
| 10. |
700120636
|
[2] |
CLAMP
|
HFI
|
| 11. |
63693
|
[2] |
PIN
|
CAS
5/8 x 2 CLEVIS PIN
|
| 12. |
62182
|
[4] |
PIN
|
CAS
5/32 x 1-1/4 COTTER PIN Superseded by part number: 86523851
|
| 13. |
7746555
|
[2] |
ELBOW
|
CAS
90deg. ELBOW Superseded by part number: 76344
|
| 14. |
8746555
|
[1] |
TEE - adapter
|
|
| 15. |
700709244
|
[1] |
HOSE
|
CAS
- hydraulic
|
| 16. |
700709243
|
[1] |
HOSE
|
CAS
- hydraulic
|
| . . |
7701188
|
[2] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 x 1-1/4 C Superseded by part number: 87670
|
| . . |
701235
|
[2] |
BOLT,1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 x 1-1/2 C
|
| . . |
700013
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 RHSNB
|
| . . |
68767
|
[1] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 1 3/4", G5
|
CAS
3/8-16 x 1-3/4 RHSNB Superseded by part number: 86508775
|
| . . |
7700073
|
[1] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2", Gr 5
|
CAS
3/8-16 x 2 RHSNB Superseded by part number: 280661
|
| . . |
704031
|
[4] |
NUT
|
NNA
1/2-13 H Superseded by part number: 425-108, 425-108, NLS
|
| . . |
231-5145
|
[2] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
5/16-18 HFSLN Superseded by part number: 72187067, 145458
|
| . . |
704213
|
[2] |
NUT
|
CAS
3/8-16 HTLN Superseded by part number: 88902
|
| . . |
80679
|
[4] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
