凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (8-18) - HYDRAULIC ASSEMBLY - RIGHT (TAILGATE) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
567 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700709155
|
[1] |
CYLINDER
|
CAS
- hydraulic (S.N. CVH0012001 thru CFH0012516)
|
| . . |
700711510
|
[1] |
CYLINDER
|
CAS
- hydraulic (S.N. CFH0012517 and later) Superseded by part number: 700715833
|
| 2. |
700710292
|
[2] |
PIN
|
CAS
1 x 2-3/4 CLEVIS PIN
|
| 3. |
7891815
|
[2] |
HOSE ASSY.
|
CAS
HOSE - hydraulic
|
| 4. |
7746555
|
[2] |
ELBOW
|
CAS
90deg. ELBOW (includes item 5) Superseded by part number: 76344
|
| 5. |
738468
|
[2] |
O-RING
|
IH
|
| 6. |
62299
|
[2] |
PIN
|
CAS
1/4 x 1-1/2 COTTER PIN Superseded by part number: 80753
|
| 7. |
7021728
|
[1] |
STRAP
|
CAS
TIE - cable Superseded by part number: 529070, 529070, NLS
|
