凯斯零件查询(8430) - CASE IH ROUND BALER (1/88-12/00) (6-04) - SHIELD AND BALE SIZE INDICATOR ASSEMBLIES (RIGHT-FRONT) Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
750 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700120617
|
[1] |
FLANGE
|
HFI
- front, right
|
| 2. |
700707437
|
[1] |
COUNTER
|
CAS
- bale (includes hardware)
|
| 3. |
700707234
|
[1] |
BUTTON
|
IH
KNOB
|
| 4. |
700115974
|
[1] |
SUPPORT
|
HFI
MOUNT - switch
|
| 5. |
700709602
|
[1] |
WASHER,5/16"
|
CAS
5/16 WIDE PLAIN WASHER Superseded by part number: 495-61034
|
| 6. |
700115973
|
[3] |
SPACER
|
CAS
|
| 7. |
700120620
|
[1] |
LINK
|
HFI
- indicator
|
| 8. |
700120619
|
[1] |
ANGLE
|
HFI
- guide, indicator
|
| 9. |
700115976
|
[1] |
INDICATOR
|
HFI
|
| . . |
703579
|
[1] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5, Full Thd
|
CAS
5/16-18 x 1 C
|
| . . |
700013
|
[3] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 RHSNB
|
| . . |
7700065
|
[6] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 x 3/4 RHSNB Superseded by part number: 280430
|
| . . |
7883325
|
[3] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
704015
|
[1] |
NUT,5/16"-18, G5
|
CAS
5/16-18 H Superseded by part number: 425-105, 425-105, 9635082
|
| . . |
231-4115
|
[1] |
NUT,5/16"-18, GB
|
CAS
5/16-18 HTLN Superseded by part number: 280736
|
| . . |
704239
|
[4] |
FRONT AXLE
|
NNA
5/16-18 HFSLN Superseded by part number: 231-5145, 231-5145, NLS
|
| . . |
704247
|
[6] |
NUT
|
CAS
3/8-16 HFSLN Superseded by part number: 231-5146, 231-5146, 280736, 231-5146, 280736, 692965, 231-5146, 280736, 692965, 87362
|
| . . |
705020
|
[1] |
LOCK WASHER
|
CAS
5/16" Superseded by part number: 492-11031, 492-11031, NLS
|
