沃尔沃零件查询4400 Exhaust cooling 97297, 992994400 NoneNoneNoneAutodata Volvo online
广数供应链运营团队, 14 02月, 2025，浏览：
993 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 5. |
|
[0001] |
Anchorage
|
|
| 50. |
|
[0001] |
Protecting plate
|
|
| 51. |
VOE13970947
|
[0004] |
Hexagon screw
|
|
| 52. |
VOE941908
|
[0004] |
Spring washer
|
|
| 53. |
VOE971071
|
[0004] |
Hexagon nut
|
|
| 54. |
VOE4824275
|
[0001] |
Profile
|
L=140
|
| 55. |
|
[0001] |
Plate
|
|
| 56. |
VOE13955295
|
[0002] |
Screw
|
|
| 57. |
VOE13955894
|
[0004] |
Washer
|
|
| 58. |
VOE955782
|
[0002] |
Hexagon nut
|
|
| 6. |
|
[0001] |
Anchorage
|
|
| 7. |
|
[0002] |
Tensioning band
|
|
| 8. |
VOE13970956
|
[0004] |
Hexagon screw
|
|
| 9. |
VOE941908
|
[0004] |
Spring washer
|
|
| 1. |
VOE4774823
|
[0001] |
Tank
|
|
| 10. |
VOE971071
|
[0004] |
Hexagon nut
|
|
| 11. |
VOE13970972
|
[0010] |
Hexagon screw
|
|
| 12. |
VOE940280
|
[0010] |
Spring washer
|
|
| 13. |
VOE13971072
|
[0010] |
Hexagon nut
|
|
| 14. |
VOE4822677
|
[0001] |
Filler cap
|
|
| 15. |
VOE914396
|
[0002] |
Plug
|
|
| 16. |
VOE11000127
|
[0001] |
Drain cock
|
|
| 17. |
VOE914363
|
[0001] |
None
|
|
| 18. |
VOE13961607
|
[0002] |
Nipple
|
|
| 19. |
VOE13943474
|
[0004] |
Hose clamp
|
|
| 2. |
|
[0001] |
Anchorage
|
|
| 20. |
VOE952969
|
[REQ] |
Hose
|
L=2000
|
| 21. |
VOE952969
|
[REQ] |
Hose
|
L=1800
|
| 22. |
VOE4854351
|
[0001] |
Tube
|
|
| 23. |
VOE956985
|
[0001] |
Fitting nut
|
|
| 24. |
VOE956971
|
[0001] |
Ferrule
|
|
| 25. |
VOE192639
|
[0001] |
Nipple
|
|
| 26. |
VOE13947624
|
[0001] |
Plane gasket
|
|
| 27. |
VOE4774826
|
[0001] |
Exhaust pipe
|
|
| 28. |
VOE952630
|
[0001] |
Clamp
|
|
| 29. |
VOE13955272
|
[0001] |
Screw
|
|
| 3. |
|
[0001] |
Anchorage
|
|
| 30. |
VOE13941906
|
[0001] |
Washer
|
|
| 31. |
VOE13955781
|
[0001] |
Nut
|
|
| 32. |
VOE952626
|
[0001] |
Clamp
|
|
| 33. |
VOE952635
|
[0004] |
Clamp
|
|
| 34. |
VOE13955272
|
[0003] |
Screw
|
|
| 35. |
VOE13955781
|
[0003] |
Nut
|
|
| 36. |
VOE4774768
|
[0001] |
Pipe elbow
|
|
| 37. |
VOE479976
|
[0001] |
Plug
|
|
| 38. |
VOE947623
|
[0001] |
Gasket
|
|
| 39. |
VOE4773684
|
[0001] |
Gasket
|
|
| 4. |
|
[0001] |
Anchorage
|
|
| 40. |
VOE4774757
|
[0001] |
Water injector
|
|
| 41. |
VOE13970948
|
[0004] |
Hexagon screw
|
|
| 42. |
VOE941908
|
[0004] |
Spring washer
|
|
| 43. |
VOE971071
|
[0004] |
Hexagon nut
|
|
| 44. |
|
[0001] |
Anchorage
|
|
| 45. |
VOE13970950
|
[0001] |
Hexagon screw
|
|
| 46. |
VOE941908
|
[0001] |
Spring washer
|
|
| 47. |
VOE971071
|
[0001] |
Hexagon nut
|
|
| 48. |
VOE4774675
|
[0001] |
Clamp
|
|
| 49. |
VOE4774762
|
[0001] |
Nozzle
|
|
