神钢零件查询(6D14) - MITSUBISHI DIESEL ENGINE - K904C, K907B, K907C & YS750-2 (1/77-12/06) (06-004) - RADIATOR (P/N-ME039527) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
836 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-19. | VAME039527 | [1] | RADIATOR & OIL COOLER ASSY (FOR M0 ONLY) FF: PARTS | |
| 1-25. | VA3184794002 | [1] | RADIATOR & OIL COOLER ASSY (FOR M1 ONLY) FF: PARTS | |
| 1. | VAME039528 | [1] | OIL COOLER ASSY (FOR M0 ONLY) FF: PARTS | |
| 1. | VA3184794022 | [1] | OIL COOLER ASSY (FOR M1 ONLY) | |
| 2. | VAMF243680 | [8] | B0LT,W/WSR 10X25 (FOR M0 ONLY) PARTS | |
| . . | VAMF100052 | [8] | BOLT 8X14 (FOR M1 ONLY) | |
| . . | VAMF430006 | [8] | NUT | KOBNUT 10 (FOR M0 ONLY) Superseded by part number: VAF230510000 |
| . . | VAMF450405 | [8] | WASHER | KOBWASHER,SPG 8 (FOR M1 ONLY) Superseded by part number: 132502A1 |
| . . | VAMF450006 | [8] | NUT | KOBWASHER,PLAIN 10 (FOR M0 ONLY) Superseded by part number: 133247A1 |
| . . | VAMF450005 | [8] | WASHER | KOBPLAIN 8 (FOR M1 ONLY) |
| 2-14. | VA3184792050 | [1] | RADIATOR SUB ASSY 19.5L (FOR M0 ONLY) PARTS | |
| 2-14. | VA3184794010 | [1] | RADIATOR SUB ASSY 19.5L (FOR M1 ONLY) PARTS | |
| 3. | VA3184794030 | [1] | RADIATOR CORE ASSY PARTS | |
| . . | VAMC000039 | [1] | RADIATOR CAP | KOBCAP,PRESS. |
| . . | VA3164705800 | [1] | CHAIN PARTS | |
| 5. | VAME008204 | [2] | CLIP PARTS | |
| 6. | VA3184793400 | [1] | PIPE, OVERFLOW L=1800 (FOR M0 ONLY) PARTS | |
| 6. | VA3084706040 | [1] | PIPE, OVERFLOW L=1500 (FOR M1 ONLY) | |
| 6-A. | VAME059255 | [1] | CLIP PARTS | |
| 7. | VA3164705200 | [1] | COCK,DRAIN PARTS | |
| 8. | VA3174780500 | [1] | PIPE,DRAIN L=150 PARTS | |
| 9. | VA3184795200 | [1] | FRAME (FOR M0 ONLY) PARTS | |
| 9. | VA3184791200 | [1] | FRAME (FOR M1 ONLY) PARTS | |
| 10. | VA3084706080 | [1] | SEAT,RUBBER PARTS | |
| 11. | VA3184799900 | [2] | CLAMP PARTS | |
| 12. | VA3084706110 | [2] | SEAT,RUBBER PARTS | |
| 13. | VAMF100055 | [8] | BOLT | KOBBOLT 8X20 |
| 14. | VAME008205 | [1] | SHIM PARTS | |
| 15. | VA3184790700 | [1] | SHROUD,FAN PARTS | |
| 19. | VAMF240050 | [8] | BOLT | SMBOLT,W/WSR 8X14 (FOR M0 ONLY) |
| 19. | VAMF100052 | [8] | BOLT 8X14 (FOR M1 ONLY) | |
| 22. | VA3184794101 | [1] | PLATE,BAFFLE T=1.2 (FOR M1 ONLY) PARTS | |
| 23. | VA3184794202 | [1] | PLATE,BAFFLE T=1.2 (FOR M1 ONLY) PARTS | |
| 24. | VA3184794302 | [1] | PLATE,BAFFLE T=1.2 (FOR M1 ONLY) PARTS | |
| 25. | VAMF240050 | [9] | BOLT | SMBOLT, W/WSR 8X14 (FOR M1 ONLY) |
