神钢零件查询(6D14) - MITSUBISHI DIESEL ENGINE - K904C, K907B, K907C & YS750-2 (1/77-12/06) (06-015) - FLYWHEEL PTO Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
511 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-15. | VAME039239 | [1] | FLYWHEEL PTO HEAD ASSY FF : | |
| 1. | VAME038175 | [2] | CASE,F/W PTO GEAR | |
| 2. | VAME038194 | [2] | GEAR,PTO Z=42 | |
| 3. | VAME038108 | [1] | SHAFT,PTO | |
| 4. | VAME060206 | [2] | COTTER | |
| 5. | VAME038111 | [1] | SPACER | |
| 6. | VAMH040003 | [2] | BEARING,BALL | |
| 7. | VAMF522240 | [1] | RING,SNAP 72 | |
| 8. | VAME062198 | [1] | FLANGE | |
| 9. | VAMF431108 | [1] | NUT,SLOTTED 18 | |
| . . | VAMF472086 | [1] | PIN | KOBPIN,SPLIT 4X35 Superseded by part number: 133237A1 |
| 10. | VAMH005010 | [1] | WASHER 18 | |
| 11. | VAME060203 | [1] | CASE,OILSEAL | |
| 12. | VAMH034013 | [1] | OILSEAL | |
| 13. | VAME060201 | [1] | COVER | KOBGASKET,COVER |
| 14. | VA3110705101 | [1] | CAP,SEAL 75 | |
| 15. | VAMF240053 | [3] | BOLT | KOBBOLT,W/WSR 8X20 |
| 16. | VMH000194 | [3] | BOLT,W/WSR 10X95 | |
| 17. | VAMF130572 | [7] | BOLT 10X40 | |
| . . | VAMF450406 | [7] | WASHER | KOBWASHER,SPG 10 |
| 18. | VAMH037181 | [1] | CONNECTOR 10 | |
| 19. | VAME034114 | [1] | PIPE,OIL | |
| 20. | VAME038114 | [1] | SHIM T=0.1 | |
| 20. | VAME038115 | [1] | SHIM T=0.2 | |
| 20. | VAME038116 | [1] | SHIM T=0.3 | |
| 21. | VAME038195 | [2] | GEAR Z=53 | |
| 22. | VAME038107 | [1] | SHAFT,IDLER NO.3 | |
| 23. | VAME038109 | [1] | SPACER | |
| 24. | VAME060206 | [2] | COTTER | |
| 25. | VAME038111 | [1] | SPACER | |
| 26. | VAMF522240 | [2] | RING,SNAP 72 | |
| 27. | VAMH040003 | [2] | BEARING,BALL | |
| 28. | VAMF430730 | [1] | NUT | KOBNUT,JAM 18 |
| 29. | VAME060205 | [1] | WASHER | |
| 30. | VA3110705101 | [1] | CAP,SEAL 75 | |
| 31. | VAME020513 | [1] | COVER | |
| 32. | VAME060201 | [1] | COVER | KOBGASKET,COVER |
| 33. | VAMF240053 | [3] | BOLT | KOBB0LT,W/WSR 8X20 |
| 34-35. | VAME032174 | [1] | IDLER ASSY N0.1 | |
| 34. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR,IDLER Z=26,52 |
| 35. | VAME020488 | [1] | BUSHING | KOBBUSHING |
| 36. | VAME032561 | [1] | SHAFT,IDLER | |
| 37. | VAMH000232 | [1] | BOLT 12X125 | |
| 38-40. | VAME032707 | [1] | CRANKSHAFT GEAR ASSY, Start Year: 01-APR-83 | |
| 38-40. | VAME038795 | [1] | CRANKSHAFT GEAR ASSY, Years: -01-MAR-83 | |
| 38. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR,CRANKSHAFT Z=42 |
| 39. | VAME472407 | [1] | PIN,DOWEL 14X28 | |
| 40. | VAME665543 | [1] | CAP,SEALING 45 | |
| 41. | VAME660063 | [1] | SHEET | KOBGASKET 10 |
