| 1. |
231-5144
|
[2] |
SERRATED NUT,Flg, USR, 1/4"-20
|
CAS
Superseded by part number: 523282, 72187066
|
| 2. |
866061
|
[1] |
EYEBOLT
|
CAS
|
| 3. |
700710131
|
[1] |
TRANSFER BOX
|
IH
GEARBOX ASSEMBLY Superseded by part number: 700725114
|
| 4. |
413-828
|
[3] |
BOLT,Hex, 1/2" - 13 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 9707516, 72187217
|
| 5. |
705541
|
[7] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 6. |
700135028
|
[1] |
SHEAVE
|
HFI
- 4 groove
|
| 7. |
240
|
[2] |
KEY,Gib, 3/8" Sq x 2 1/2"
|
IH
3/8 X 2-1/2 KEY - gib
|
| 8. |
241-1418
|
[1] |
SPRING CLIP
|
CAS
LINK - connector #80
|
| 9. |
654437R91
|
[1] |
CHAIN (AG)
|
IH
CHAIN - roller, #80 (10 foot bulk)
|
| 10. |
11-1248
|
[1] |
CARRIAGE BOLT,Short NK, 3/4"-10 x 7 1/2", G2
|
CAS
3/4-10 X 3 RHSNB
|
| 11. |
232-53112
|
[1] |
FLANGE NUT,Flg, 3/4"-10
|
CAS
3/4-10 HFTLN GR/G Superseded by part number: 86512372
|
| 12. |
700135030
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET WA - 80B12 tooth
|
| 13. |
51200277
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - idler, 12 tooth
|
| 14. |
6344105
|
[1] |
SPACER
|
HFI
BUSHING
|
| 15. |
700135022
|
[1] |
SHAFT
|
HFI
- lower
|
| 16. |
700135023
|
[1] |
HOUSING
|
HFI
ASSEMBLY - bearing (includes item 18)
|
| 17. |
700710984
|
[4] |
SCREW,Hex Flg, 1/2" x 1 1/4", G8 NC
|
CAS
1/2-13 X 1-1/4 HFS GR8
|
| 18. |
712158
|
[1] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
BEARING - spherical Superseded by part number: 47577203
|
| 19. |
50583
|
[2] |
FLANGED BEARING
|
IH
Superseded by part number: 86979948
|
| 20. |
51318
|
[2] |
BEARING
|
IH
- spherical Superseded by part number: 668718R92, 47577169
|
| 21. |
433-820
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 22. |
231-5348
|
[12] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 23. |
6531362
|
[3] |
BUSHING
|
CAS
|
| 24. |
413-848
|
[1] |
BOLT,Hex, 1/2" - 13 x 3", Gr 5
|
IH
1/2-13 X 3 C Superseded by part number: 72187218, 87339
|
| 25. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 26. |
485-13812
|
[1] |
SET SCREW,Sq Hd, 3/8"-16 x 3/4"
|
CAS
3/8-16 X 3/4 CPSQHSS Superseded by part number: 87616
|
| 27. |
700714791
|
[1] |
YOKE
|
CAS
U-JOINT ASM, SINGLE
|
| 28. |
Q1443
|
[1] |
KEY,5/16" Sq x 1 1/2", Par
|
IH
5/16 X 5/16 X 1-1/2 KEY
|
| 29. |
433-824
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 X 1-1/2 RHSNB Superseded by part number: 280420, 72187237
|
| 30. |
700110467
|
[1] |
BEARING ASSY,44.45 mm ID x 92.44 mm OD x 29 mm
|
L
BEARING ASSEMBLY - 85mm (includes item 20)
|
| 31. |
413-852
|
[3] |
BOLT,Hex, 1/2" - 13 x 3-1/4", Gr 5
|
CAS
1/2-13 X 3-1/4 C Superseded by part number: 72187219, 88043
|
| 32. |
700135021
|
[1] |
SHAFT
|
HFI
- upper
|
| 33. |
700135032
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET WA - 80B36 tooth
|
| 34. |
861088
|
[1] |
BUCKET TOOTH KEY
|
IH
1/2 X 2 KEY - gib
|
| 35. |
700135029
|
[1] |
SHEAVE
|
HFI
- 4 groove
|
| 36. |
700716005
|
[1] |
BELT
|
CAS
- 4 groove power band
|
