| 1. |
396-21066
|
[9] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 2. |
52233
|
[2] |
BUSHING
|
CAS
5/8 X 14 GAUGE NRMB Superseded by part number: 51200381
|
| 3. |
140319
|
[1] |
BOLT,1/2" - 13 x 5"
|
CAS
BOLT - eye
|
| 4. |
541857R92
|
[2] |
SPROCKET,15T
|
IH
IDLER - sprocket, 15 tooth
|
| 5. |
700135025
|
[1] |
SUPPORT
|
HFI
WA
|
| 6. |
121-237
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8-16 X 1-1/4 HFS GR8 Superseded by part number: 87327172
|
| 7. |
232-5316
|
[4] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 8. |
700134911
|
[1] |
HUB
|
HFI
ASSEMBLY
|
| 9. |
195-2139
|
[3] |
WASHER,36.52mm ID x 57.15mm OD x 2.03mm Thk
|
IH
1-3/8 X 14 GAUGE NRMB
|
| 10. |
700133291
|
[1] |
CLUTCH
|
HFI
ASSEMBLY
|
| 11. |
Q3936
|
[1] |
KEY,Gib, 5/16" Sq x 2 1/2"
|
IH
5/16 X 2-1/2 GIB KEY
|
| 12. |
1791D
|
[1] |
CHAIN (AG),#50, 192 Links x 15.88mm = 3048mm
|
IH
CHAIN - roller, #50 (10 foot bulk)
|
| 13. |
241-1315
|
[1] |
LINK, CONNECTING
|
CAS
LINK - connector, #50 Superseded by part number: 87034815
|
| 14. |
700715085
|
[1] |
BRONZE BUSHING
|
HFI
BUSHING - bronze
|
| 15. |
Q3929
|
[1] |
KEY,Gib, 5/16" Sq x 1 1/2"
|
IH
5/16 X 1-1/2 GIB KEY
|
| 16. |
700132441
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET WA - 60B26 tooth
|
| 17. |
700132437
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET WA - 22 and 13 tooth (includes item 14)
|
| 18. |
413-516
|
[6] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5
|
CAS
Superseded by part number: 9635884, 72187198
|
| 19. |
492-11031
|
[6] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 20. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 21. |
241-1316
|
[1] |
LINK,19.05mm Pitch
|
CAS
LINK - connector, #60
|
| 22. |
7086002
|
[1] |
CHAIN (AG)
|
CAS
ROLLER CHAIN - #60 (10 foot bulk) Superseded by part number: 611362R91X, 241-1316
|
| 23. |
483-1388
|
[2] |
SET SCREW,Hex Soc, 3/8"-16 x 1/2"
|
CAS
3/8-16 X 1/2 CPHSSS NP Superseded by part number: 87023136
|
| 24. |
700132452
|
[1] |
COLLAR
|
HFI
|
| 25. |
858027
|
[1] |
COMPRESSION SPRING
|
CAS
SPRING - compression
|
| 26. |
705541
|
[2] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 27. |
425-108
|
[4] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex, FTLN GR/G 1/2"-13, G5 Superseded by part number: 280431
|
| 28. |
433-1048
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 3", Gr 5
|
CAS
5/8-11 X 3 RHSNB
|
| 29. |
232-53110
|
[2] |
FLANGE NUT,Flg, 5/8"-11
|
CAS
5/8-11 HFTLN GR/G Superseded by part number: 84180923
|
| 30. |
409-7612
|
[2] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
| 31. |
700132447
|
[1] |
LEVER
|
HFI
WA
|
| 32. |
230-4118
|
[1] |
LOCK NUT,1/2"-13, GA
|
CAS
1/2-13 HTLN GR/B
|
| 33. |
700132453
|
[1] |
CLEVIS
|
HFI
|
| 34. |
700135027
|
[1] |
ROD
|
HFI
|
| 35. |
432-1024
|
[2] |
COTTER PIN,5/32" x 1 1/2"
|
CAS
5/32" x 1 1/2" Superseded by part number: 72187233, 88350
|
| 36. |
66183
|
[1] |
SHAFT
|
NNA
Superseded by part number: 066183
|
| 37. |
63677
|
[2] |
WASHER
|
IH
1/2 X 1-27/64 CLEVIS PIN Superseded by part number: 2975160, 2975160, IH63677
|
| 38. |
700132442
|
[1] |
LEVER
|
HFI
WA
|
