神钢零件查询(6D14) - MITSUBISHI DIESEL ENGINE - K904C, K907B, K907C & YS750-2 (1/77-12/06) (03-010) - FUEL FILTER Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
140 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-7. | VAME035827 | [1] | FILTER SET FUEL FILTER ASSY | FILTER SET FUEL FILTER ASSY |
| 1. | VAME035828 | [1] | FUEL HEAD,FUEL FILTER | FUEL HEAD,FUEL FILTER |
| 2. | VAMH035069 | [4] | GASKET | KOBGASKET 14 Superseded by part number: 133378A1 |
| 3. | VAMH037087 | [2] | BOLT | KOBBOLT,CONNECTOR |
| 4. | VAMH037084 | [1] | GLOW PLUG | KOBPLUG,AIR Superseded by part number: 77270641, VAME016894 |
| 5. | VAMH035067 | [1] | GASKET | KOBGASKET 8 |
| 6. | VAME035829 | [1] | ELEMENT ELEMENT,FUEL FILTER | ELEMENT ELEMENT,FUEL FILTER |
| 7. | VAME016825 | [1] | COVER DUST COVER,DUST | COVER DUST COVER,DUST |
| 10. | VAMF300843 | [2] | SCREW | KOBB0LT,W/WSR 10X25 Superseded by part number: 133250A1 |
| 11. | VAME035839 | [1] | BRACKET,FUEL FILTER (FOR M0,M1 ONLY) | |
| 11. | VAME038720 | [1] | BRACKET BRACKET,FUEL FILTER (FOR M2 ONLY) | BRACKET BRACKET,FUEL FILTER (FOR M2 ONLY) |
| 12. | VAMF241255 | [2] | BOLT | KOBBOLT,W/WSR 8X25 (FOR M1 ONLY) |
| 12. | VAMF241268 | [2] | BOLT | KOBBOLT,W/WSR 8X75 (FOR M2 ONLY) |
