| 1. |
413-1244
|
[2] |
BOLT,Hex, 3/4" - 10 x 2-3/4", Gr 5
|
CAS
3/4-10 X 2-3/4 C Superseded by part number: 80280173
|
| 2. |
492-11075
|
[12] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 3. |
413-1232
|
[10] |
BOLT,Hex, 3/4" - 10 x 2", Gr 5
|
CAS
Superseded by part number: 88557
|
| 4. |
700711166
|
[6] |
WASHER
|
CAS
3/4 HARDENED WIDE PLAIN WASHER
|
| 5. |
700707981
|
[4] |
SCREW,FLAT, 3/4" - 10 x 1-3/4"
|
L
3/4-10 X 1-3/4 HSFCHCS - special
|
| 6. |
214817
|
[6] |
SPACER
|
CAS
BUSHING
|
| 7. |
700135023
|
[2] |
HOUSING
|
HFI
ASSEMBLY - bearing (includes item 11)
|
| 8. |
413-848
|
[6] |
BOLT,Hex, 1/2" - 13 x 3", Gr 5
|
IH
1/2-13 X 3 C Superseded by part number: 72187218, 87339
|
| 9. |
705541
|
[6] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 10. |
700132410
|
[4] |
BEARING ASSY,50.8 mm ID x 100 mm OD x 10, 7 mm
|
HFI
BEARING ASSEMBLY - 100mm (includes item 11) Superseded by part number: 700150032
|
| 11. |
712158
|
[6] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
BEARING - spherical Superseded by part number: 47577203
|
| 12. |
700715063
|
[4] |
TAPE
|
CAS
- adhesive
|
| 13. |
700132354
|
[12] |
SLEEVE
|
CAS
|
| 14. |
8050825
|
[12] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
- cylindrical Superseded by part number: F82059
|
| 15. |
700132353
|
[1] |
SHAFT
|
HFI
|
| 16. |
F82059
|
[2] |
BEARING ASSY,38.1mm ID x 80mm OD x 22mm W
|
IH
BEARING - cylindrical (includes collar)
|
| 17. |
433-824
|
[12] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 X 1-1/2 RHSNB Superseded by part number: 280420, 72187237
|
| 18. |
231-5348
|
[12] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 19. |
700135117
|
[2] |
RING
|
HFI
- grass
|
| 20. |
700132345
|
[1] |
ROLLER
|
HFI
ASSEMBLY
|
| 21. |
700132351
|
[2] |
ROLLER
|
HFI
ASSEMBLY (includes items 12, 13, 14, 15 and 16) Superseded by part number: 700148218
|
| 22. |
700135112
|
[1] |
ROLLER
|
HFI
ASSEMBLY - top
|
| 23. |
700132350
|
[1] |
ROLLER
|
HFI
ASSEMBLY (includes item 25)
|
| 24. |
700100927
|
[10] |
HUB
|
L
|
| 25. |
700710914
|
[2] |
BEARING, ROLLER, CYL,55.56mm ID x 100mm OD x 24mm W
|
L
BEARING - cylindrical
|
| 26. |
700116217
|
[5] |
ROLL
|
IH
ER ASSEMBLY (includes item 14)
|
| 27. |
700125071
|
[2] |
HUB
|
CAS
|
