沃尔沃零件查询4500 Oil cooler with fitting parts4500 NoneNoneNoneAutodata Volvo online
广数供应链运营团队, 14 02月, 2025，浏览：
242 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 4. |
VOE961390
|
[0002] |
Disc spring
|
|
| 5. |
VOE930844
|
[0002] |
Plain washer
|
|
| 6. |
VOE970996
|
[0002] |
Hexagon screw
|
|
| 7. |
VOE959236
|
[0002] |
Hex. socket screw
|
|
| 8. |
VOE959241
|
[0002] |
Hex. socket screw
|
|
| 1. |
VOE4771322
|
[0001] |
Oil cooler
|
|
| 9. |
VOE941908
|
[0004] |
Spring washer
|
|
| 10. |
VOE970945
|
[0002] |
Hexagon screw
|
|
| 11. |
VOE941908
|
[0002] |
Spring washer
|
|
| 12. |
VOE4851351
|
[0001] |
Anchorage
|
|
| 13. |
VOE4851352
|
[0001] |
Seal
|
|
| 14. |
|
[0001] |
Flat iron
|
|
| 15. |
VOE13955294
|
[0006] |
Screw
|
|
| 16. |
VOE4851357
|
[0002] |
Seal
|
|
| 17. |
VOE4851356
|
[0001] |
Anchorage
|
V
|
| |
VOE4851428
|
[0001] |
Anchorage
|
H
|
| 18. |
|
[0002] |
Flat iron
|
|
| 2. |
VOE4776758
|
[0001] |
Bracket
|
V
|
| 19. |
VOE13955294
|
[0016] |
Screw
|
|
| 20. |
VOE13960141
|
[0008] |
Washer
|
|
| 21. |
VOE4851446
|
[0001] |
Seal
|
|
| 22. |
VOE4851445
|
[0001] |
Support plate
|
|
| 23. |
VOE13955294
|
[0004] |
Screw
|
|
| 24. |
VOE13960141
|
[0004] |
Washer
|
|
| 25. |
VOE931734
|
[0001] |
Hose assembly
|
|
| 26. |
VOE931735
|
[0001] |
Hose assembly
|
|
| 27. |
VOE990756
|
[0002] |
Sealing ring
|
|
| 28. |
VOE927947
|
[0004] |
Flange half
|
|
| |
VOE4776759
|
[0001] |
Bracket
|
H
|
| 29. |
VOE955297
|
[0008] |
Hexagon screw
|
|
| 30. |
VOE13941907
|
[0008] |
Washer
|
|
| 31. |
VOE943717
|
[0003] |
Clamp
|
|
| 32. |
VOE13955295
|
[0003] |
Screw
|
|
| 33. |
VOE13955894
|
[0003] |
Washer
|
|
| 34. |
VOE13964043
|
[0001] |
Joint nipple
|
|
| 35. |
VOE4851342
|
[0001] |
Tube
|
|
| 36. |
VOE957035
|
[0001] |
Nipple
|
|
| 37. |
VOE958228
|
[0001] |
O-ring
|
|
| 38. |
VOE941582
|
[0003] |
Nipple
|
|
| 3. |
VOE4776566
|
[0002] |
Pin
|
|
| 39. |
VOE14013070
|
[0003] |
Sealing washer
|
|
| 40. |
VOE4880753
|
[0001] |
Thermostat
|
|
| 41. |
VOE944258
|
[0001] |
Elbow nipple
|
|
| 42. |
VOE4851340
|
[0001] |
Tube
|
|
| 43. |
VOE957035
|
[0001] |
Nipple
|
|
| 44. |
VOE958228
|
[0001] |
O-ring
|
|
| 45. |
VOE4927411
|
[0001] |
Hose connection
|
|
| 46. |
VOE13949327
|
[0001] |
O-ring
|
|
| 47. |
VOE13970954
|
[0002] |
Hexagon screw
|
|
| 48. |
VOE941908
|
[0002] |
Spring washer
|
|
