凯斯零件查询(8435) - CASE IH SILAGE SPECIAL ROUND BALER (1/97-12/00) (6-28) - RIENK ASSEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
948 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
51292
|
[2] |
SPHERICAL BEARING,1.25" ID x 72 mm OD x 19 mm
|
IH
- spherical Superseded by part number: 84330041, 47508357
|
| 2. |
700135180
|
[1] |
SPROCKET ASSY.
|
HFI
SPROCKET WA - 80B15 tooth
|
| 3. |
249-1
|
[1] |
KEY
|
IH
1/4 X 1-3/4 GIB KEY
|
| 4. |
241-1418
|
[1] |
SPRING CLIP
|
CAS
LINK - connector #80
|
| 5. |
654437R91
|
[1] |
CHAIN (AG)
|
IH
CHAIN - roller #80 (10 foot bulk)
|
| 6. |
617863R1
|
[4] |
FLANGED BEARING
|
IH
|
| 7. |
700135179
|
[6] |
SPACER
|
HFI
|
| 8. |
433-628
|
[6] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 5
|
CAS
3/8-16 X 1-3/4 RHSNB Superseded by part number: 86508775
|
| 9. |
232-5316
|
[6] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 10. |
700125033
|
[1] |
SHAFT
|
IH
- hex
|
| 11. |
700135176
|
[5] |
WHEEL
|
HFI
RIENK WA
|
| 12. |
700133242
|
[2] |
WHEEL
|
HFI
REINK WA - outer
|
