沃尔沃零件查询2001; 2001B; 2001AG; 2001BG; 2002; 2002B; 2002D; 2002AG; 2002BG; 2003; 2003B; 2003D; 2003AG; 2003BG; 2003T; 2003TB; 2003 SOLAS; 2003B SOLAS; 2003TFuel SystemFuel System: 868396 BGEPC Volvo Penta Parts catalog
广数供应链运营团队, 14 02月, 2025，浏览：
811 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
859428
|
[1] |
Fuel pump
|
|
| 2. |
942353
|
[1] |
O-ring
|
|
| 3. |
942001
|
[2] |
Hex. socket screw
|
|
| 4. |
941906
|
[2] |
Spring washer
|
|
| 5. |
840532
|
[1] |
Fuel filter
|
|
| 6. |
970948
|
[2] |
Hexagon screw
|
|
| 7. |
976945
|
[1] |
Washer
|
|
| 8. |
860793
|
[1] |
Injection pump
|
|
| 9. |
860211
|
[1] |
Spacer
|
TH=0.2mm
|
| 9. |
838298
|
[1] |
Spacer
|
TH=0.3mm
|
| 9. |
838299
|
[1] |
Spacer
|
TH=0.6mm
|
| 9. |
838300
|
[1] |
Spacer
|
TH=0.9mm
|
| 9A. |
978961
|
[1] |
O-ring
|
|
| 10. |
924061
|
[2] |
Stud
|
|
| 11. |
955894
|
[2] |
Washer
|
|
| 12. |
955782
|
[2] |
Hexagon nut
|
|
| 13. |
840598
|
[1] |
Tappet
|
|
| 14. |
840312
|
[1] |
Screw
|
|
| 15. |
955271
|
[1] |
Hexagon screw
|
|
| 16. |
404279
|
[2] |
Clamp
|
|
| 17. |
955781
|
[1] |
Hexagon nut
|
|
| 18. |
25167
|
[1] |
Hollow screw
|
|
| 19. |
957178
|
[2] |
Gasket
|
|
| 20. |
860912
|
[1] |
Fuel pipe
|
|
| 21. |
25167
|
[2] |
Hollow screw
|
|
| 22. |
957178
|
[4] |
Gasket
|
|
| 23. |
840450
|
[1] |
Fuel pipe
|
|
| 24. |
944679
|
[1] |
Hollow screw
|
|
| 25. |
957178
|
[2] |
Gasket
|
|
| 26. |
969299
|
[1] |
Hollow screw
|
(74040)
|
| 27. |
957175
|
[2] |
Gasket
|
|
| 28. |
840485
|
[1] |
Leak-off line
|
|
| 29. |
243487
|
[1] |
Hollow screw
|
|
| 30. |
957170
|
[2] |
Gasket
|
|
| 31. |
860556
|
[1] |
Injector
|
|
| 32. |
861728
|
[1] |
Yoke
|
|
| 33. |
980336
|
[1] |
Stud
|
|
| 34. |
955894
|
[1] |
Washer
|
|
| 35. |
955782
|
[1] |
Hexagon nut
|
|
| 36. |
840916
|
[1] |
Delivery pipe
|
|
| 37. |
7726000_154
|
|
regulation system
|
|
| 38. |
952623
|
[1] |
Clamp
|
|
| 39. |
955272
|
[1] |
Hexagon screw
|
|
| 40. |
190990
|
[2] |
Gasket
|
Included in injector.
|
| 41. |
243487
|
[1] |
Hollow screw
|
Included in injector.
|
| 42. |
858006
|
[1] |
Hollow screw
|
Marked out
|
| 43. |
957175
|
[2] |
Gasket
|
|
