纽荷兰零件查询(3) - CYL POWERTRAIN (12A01) - ADAPTER ASSEMBLY New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
541 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 22. | E3NN17N264AA | [1] | ADAPTER | BASAssy., Includes: Ref. 23 thru 28, Start Year: 01-JAN-81 Superseded by part number: E4NN17N264AA |
| 23. | 81834272 | [1] | RING,49.43mm ID x 55.4mm OD x 3.18mm Thk | BAS(Replaces D3NN17N269A), Start Year: 01-JAN-81 |
| 24. | 87067S94 | [1] | O-RING,0.139" Thk x 1.859" ID, -225, Cl 5, 75 Duro | FOR1.875" ID x .139" Thk, Start Year: 01-JAN-81 Superseded by part number: 272380 |
| 25. | D3NN17N275A | [1] | SHAFT | BAS& Cable Assy., Start Year: 01-JAN-81 Superseded by part number: E9NN17N275AA |
| 26. | D3NN17N271A | [1] | SEAL,7.92mm ID x 14.27mm OD x 3.96mm Thk | BAS, Start Year: 01-JAN-81 |
| 27. | 81834271 | [1] | SLEEVE,7.95mm ID x 11.15mm OD x 31.8mm L | BASBearing, Start Year: 01-JAN-81 |
| 28. | 86977738 | [1] | BOLT,Hex, 5/16" - 24 x 7/8", Gr 5, Full Thd | NHScrew, Cap, HH, G5, 5/16"-24 x 7/8", Start Year: 01-JAN-81 |
| . . | D5NN11A578A | [1] | NUT | BAS, Start Year: 01-JAN-81, Serial Range: Switch-Panel Superseded by part number: 81806704 |
