现代零件查询HLF15/18-5 ELECTRIC 2(TIER II)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
933 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 4. |
21FW-10080
|
[1] |
HARNESS-FUEL
|
|
| 10. |
21L8-30720
|
[1] |
STRAP-EARTH
|
|
| 13. |
21FW-10052
|
[1] |
CONNECTOR-BRACKET
|
|
| 15. |
21FW-10070
|
[1] |
BRACKET-FUSE BOX
|
|
| 16. |
FAC0100140
|
[2] |
RUBBER
|
|
| 18. |
F23830010
|
[1] |
COMBINATION SW ASSY
|
|
| 18. |
F23830011
|
[1] |
COMBINATION SW ASSY
|
|
| 18. |
F23830010
|
[1] |
COMBINATION SW ASSY
|
|
| 18. |
F23830011
|
[1] |
COMBINATION SW ASSY
|
|
| 18-1. |
01507500AA
|
[1] |
GEAR SELECTOR(F/R 1)
|
|
| 18-1. |
21FJ-10320
|
[1] |
GEAR SELECTOR
|
|
| 18-1. |
01507500AA
|
[1] |
GEAR SELECTOR(F/R 1)
|
|
| 18-1. |
21FJ-10320
|
[1] |
GEAR SELECTOR
|
|
| 18-2. |
01507600AB
|
[1] |
T/S,LIGHT,HORN
|
|
| 18-2. |
21FJ-10330
|
[1] |
COMBINATION SWITCH
|
|
| 18-2. |
01507600AB
|
[1] |
T/S,LIGHT,HORN
|
|
| 18-2. |
21FJ-10330
|
[1] |
COMBINATION SWITCH
|
|
| 19. |
F12140020
|
[1] |
GROMMET
|
|
| 25. |
21FK-10500
|
[1] |
ACCELERATOR PEDAL
|
|
| 31. |
S015-060356
|
[4] |
BOLT-HEX
|
|
| 32. |
S411-060006
|
[4] |
WASHER-SPRING
|
|
| 34. |
S035-081526
|
[2] |
BOLT-W/WASHER
|
|
| 37. |
F12830090
|
[1] |
SWITCH-BRAKE
|
|
| 37. |
F12830090
|
[1] |
SWITCH-BRAKE
|
|
| 41. |
S543-200002
|
[2] |
CLAMP-TUBE
|
|
| 42. |
FAC0300110
|
[1] |
SENSOR-T/M OIL TEMP
|
|
| 43. |
P392-160000
|
[1] |
WASHER-COPPER
|
|
| 44. |
FAC0300300-02
|
[1] |
ADAPTOR
|
|
| 49. |
F23842010
|
[1] |
STROBE LAMP-RED
|
|
| 50. |
F12110120
|
[1] |
BRACKET-BEACON
|
|
| 51. |
S403-061006
|
[4] |
WASHER-PLAIN
|
|
| 53. |
S037-102026
|
[2] |
BOLT-W/WASHER
|
|
| 54. |
320008040
|
[1] |
WARNING BUZZER
|
|
| 55. |
21E3-0011
|
[1] |
RELAY
|
|
| 56. |
S161-050206
|
[1] |
SCREW-RD HD
|
|
| 57. |
S035-062026
|
[2] |
BOLT-W/WASHER
|
|
| 58. |
S018-120252
|
[1] |
BOLT-HEX
|
|
| 59. |
S403-121002
|
[1] |
WASHER-PLAIN
|
|
| 60. |
S411-120002
|
[1] |
WASHER-SPRING
|
|
| 61. |
S593-000902
|
[1] |
CLIP-HARNESS
|
|
| 62. |
21FG-10040
|
[1] |
LAMP-LICENSE(12V)
|
|
| 62-1. |
S860-000300
|
[2] |
BULB
|
|
| 63. |
S552-050203
|
[4] |
CLAMP-BAND
|
|
| 66. |
S205-061002
|
[1] |
NUT-HEX
|
|
| 67. |
S411-060002
|
[1] |
WASHER-SPRING
|
|
| 68. |
S552-102370
|
[2] |
CLAMP-BAND
|
|
| 69. |
S035-082026
|
[3] |
BOLT-W/WASHER
|
|
| 72. |
S035-061526
|
[1] |
BOLT-W/WASHER
|
|
| 72. |
S035-061526
|
[2] |
BOLT-W/WASHER
|
|
| 72. |
S035-061526
|
[1] |
BOLT-W/WASHER
|
|
| 72. |
S035-061526
|
[2] |
BOLT-W/WASHER
|
|
| 73. |
FAC0300110
|
[1] |
SENSOR-T/M OIL TEMP
|
|
| 101. |
21E3-0004
|
[1] |
RELAY-START
|
|
| 101. |
21FJ-10090
|
[1] |
RELAY-START
|
|
| 101. |
21E3-0004
|
[1] |
RELAY-START
|
|
| 101. |
21FJ-10090
|
[1] |
RELAY-START
|
|
| 102. |
S035-061526
|
[1] |
BOLT-W/WASHER
|
|
| 102. |
S035-061526
|
[2] |
BOLT-W/WASHER
|
|
| 102. |
S035-061526
|
[1] |
BOLT-W/WASHER
|
|
| 102. |
S035-061526
|
[2] |
BOLT-W/WASHER
|
|
| 103. |
21M8-00070
|
[1] |
HORN-HIGH
|
|
| 104. |
S035-081526
|
[1] |
BOLT-W/WASHER
|
|
| 105. |
21FD-30310
|
[1] |
BACK BUZZER(12V)
|
|
| 105. |
21FD-30311
|
[1] |
BACKUP ALARM(12V)
|
|
| 105. |
21FD-30310
|
[1] |
BACK BUZZER(12V)
|
|
| 105. |
21FD-30311
|
[1] |
BACKUP ALARM(12V)
|
|
| 106. |
S035-061526
|
[2] |
BOLT-W/WASHER
|
|
| 107. |
S593-000752
|
[1] |
CLIP-HARNESS
|
|
| 107. |
S593-000752
|
[4] |
CLIP-HARNESS
|
|
| 107. |
S593-000752
|
[1] |
CLIP-HARNESS
|
|
| 107. |
S593-000752
|
[4] |
CLIP-HARNESS
|
|
