凯斯零件查询(8440) - CASE IH ROUND BALER (1/88-12/90) (24[1]) - GEARBOX Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
410 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
7895113
|
[1] |
GEARBOX ASSY
|
HFI
GEARBOX COMPLETE Superseded by part number: 700127900, 700725114
|
| 1. |
757120
|
[2] |
CAP
|
CAS
|
| 2. |
7812373
|
[1] |
SHAFT
|
HFI
|
| 3. |
753582
|
[1] |
GASKET
|
HFI
(.005)
|
| . . |
753608
|
[1] |
GASKET
|
HFI
(.015)
|
| . . |
HFI756353
|
[1] |
GASKET
|
HFI
(.003)
|
| . . |
756361
|
[1] |
GASKET
|
HFI
(.002)
|
| 4. |
757153
|
[2] |
SEAL
|
CAS
Superseded by part number: 701519
|
| 5. |
ST991
|
[3] |
BEARING CUP
|
IH
Superseded by part number: 116210
|
| 6. |
757088
|
[2] |
CONE
|
CAS
BEARING CONE Superseded by part number: 86576984
|
| 7. |
800441
|
[1] |
RING
|
HFI
|
| 8. |
51200297
|
[2] |
KEY
|
CAS
TAPERED KEY
|
| 9. |
8806358
|
[1] |
GEAR-SET
|
HFI
SET OF GEARS (matched) Superseded by part number: 700711871
|
| 10. |
800235
|
[1] |
COLLAR
|
HFI
THRUST COLLAR Superseded by part number: 700711934
|
| 11. |
710343
|
[1] |
BEARING, ROLLER,34.938 mm ID x 19.583 mm
|
HFI
BEARING CONE Superseded by part number: 115970
|
| 13. |
757062
|
[1] |
HOUSING
|
CAS
Superseded by part number: 700100292
|
| 14. |
753939
|
[1] |
PLUG
|
HFI
VENTED PLUG
|
| 15. |
757054
|
[1] |
CAP
|
CAS
BLANK CAP
|
| 16. |
711242
|
[1] |
BEARING CUP
|
CAS
Superseded by part number: 47923369
|
| 17. |
711507
|
[1] |
ROLLER BEARING,31.77 mm ID x 16.764 mm
|
IH
BEARING CONE Superseded by part number: 84356153
|
| 18. |
753418
|
[1] |
SHIM
|
HFI
(.002)
|
| . . |
753426
|
[1] |
SHIM
|
CAS
(.005)
|
| . . |
753434
|
[1] |
SHIM
|
CAS
(.010)
|
| 19. |
757229
|
[1] |
RING, SNAP
|
CAS
RETAINER RING
|
| 20. |
700703549
|
[1] |
SHAFT
|
CAS
|
| . . |
HK52345
|
[1] |
COUNTER KIT COMPLETE
|
|
