现代零件查询HLF15/18C-5 PISTON & CRANKSHAFTEPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
630 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
MD346022
|
[1] |
CRANKSHAFT
|
|
| 2. |
MD193027
|
[4] |
CONNECTING ROD ASSY
|
|
| 2-1. |
MD193029
|
[8] |
BOLT-CONNROD
|
|
| 2-3. |
MD144215
|
[8] |
NUT-CONNROD
|
|
| 3. |
MD095201
|
[1] |
BOLT-CENTER
|
|
| 4. |
MD188289
|
[4] |
PISTON & PIN ASSY
|
|
| 4. |
MD194365
|
[4] |
PISTON & PIN ASSY
|
|
| 4. |
MD194367
|
[4] |
PISTON & PIN ASSY
|
|
| 5. |
MD368260
|
[1] |
FLYWHEEL SUB ASSY
|
|
| 5-1. |
MD153955
|
[1] |
RING GEAR-FLYWHEEL
|
|
| 6. |
MM114755
|
[1] |
BEARING-BALL
|
|
| 7. |
MD323755
|
[1] |
PULLEY-CRANKSHAFT
|
|
| 8. |
MD195833
|
[1] |
RING SET-PISTON
|
|
| 8. |
MD195835
|
[1] |
RING SET-PISTON
|
|
| 8. |
MD195837
|
[1] |
RING SET-PISTON
|
|
| 9. |
MD377400
|
[1] |
WASHER-PLAIN
|
|
| 10. |
MF450405
|
[4] |
WASHER-SPRING
|
|
| 11. |
MU000361
|
[4] |
BOLT
|
|
| 12. |
MD008959
|
[1] |
KEY-WOODRUFF
|
|
| 13. |
MD008839
|
[7] |
BOLT-FLYWHEEL
|
|
| 19. |
MD327503
|
[4] |
BEARING-CONNROD
|
|
| 19. |
MD327504
|
[4] |
BEARING-CONNROD
|
|
| 19. |
MD327505
|
[4] |
BEARING-CONNROD
|
|
