| | 3E-6328Y | [1] | ALARM GP(24-VOLT) | |
| | 167-0138Y | [1] | SWITCH GP-MAGNETIC(24-VOLT)(MAIN RELAY) | |
| | | | S/N B1L1-112 |
| | 241-8368Y | [1] | SWITCH GP-MAGNETIC(24-VOLT)(MAIN RELAY) | |
| | | | S/N B1L113-504 |
| | | | |
| | 3T-2662 | [1] | CIRCUIT BREAKER AS(15-AMPERE, AUTOMATIC RESET)(HEADLIGHT) | |
| | 6T-3642 | [1] | CIRCUIT BREAKER AS(10-AMPERE)(KEY SWITCH) | |
| | 6T-3643 | [2] | CIRCUIT BREAKER AS(15-AMPERE)(BLOWER FAN) | |
| | | | (EACH CIRCUIT BREAKER AS INCLUDES) |
| | 6V-8376 | [2] | SCREW-MACHINE(8-32X0.25-IN) | |
| | 9B-7233 | [2] | LOCKWASHER | |
| | 178-0263 | [1] | DOOR AS | |
| | 3H-0240 | [11] | WASHER(5X9.7X0.8-MM THK) | |
| | 9M-5733 | [11] | RIVET-POP | |
| | 178-0266 | [1] | HINGE AS | |
| | 188-8846 | [1] | LATCH AS | |
| | 235-2670 | [1] | HARNESS AS-BOX | |
| | 131-1497 | | TERMINAL AS-RING(10-GA TO 12-GA) | |
| | 2L-8068 | | TERMINAL-RING(10-GA TO 12-GA, 5/16-IN SCREW) | |
| | 125-7875E | | TUBE-HEAT SHRINK(7.44-MM DIA)(4-CM) | |
| | 9W-2033 | [16] | TERMINAL-BLADE(14-GA TO 16-GA) | |
| | 9W-2034 | [4] | TERMINAL-BLADE(10-GA TO 12-GA) | |
| | 5P-3454 | [1] | TERMINAL-RING(4-GA, 5/16-IN SCREW) | |
| | 128-4162 | [2] | TERMINAL AS(6-GA TO 8-GA) | |
| | 5P-1478 | [2] | TERMINAL-FORK(10-GA TO 12-GA, NO. 10 SCREW) | |
| | 5P-1475 | [4] | TERMINAL-FORK(14-GA TO 16-GA, NO. 8 SCREW) | |
| | 9W-2035 | [4] | BLOCK-FUSE | |
| | 186-3735 | [23] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 127-5483 | [1] | PLUG AS-CONNECTOR(1-PIN) | |
| | 245-0159 | [2] | PLUG AS | |
| | 245-0164 | [1] | PLUG AS(12-PIN) | |
| | 245-8023 | [1] | PLUG AS-CONNECTOR(40-PIN) | |
| | 8T-8737 | [18] | PLUG-SEAL | |
| | 245-0165 | [1] | RECEPTACLE AS | |
| | 245-0169 | [1] | RECEPTACLE AS-CONNECTOR(12-PIN) | |
| | 245-0172 | [1] | RECEPTACLE AS | |
| | 245-8027 | [1] | RECEPTACLE AS(9-PIN) | |
| | 8N-1549 | [1] | SOCKET-CONNECTOR(4-GA) | |
| | 9W-0844 | [4] | SOCKET-CONNECTOR(14-GA TO 16-GA) | |
| | 186-3736 | [36] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | | | S/N B1R1-150 |
| | 258-0585 | [1] | HARNESS AS-PANEL(CIRCUIT BREAKER) | |
| | 131-1497 | | TERMINAL AS-RING(10-GA TO 12-GA) | |
| | 2L-8068 | | TERMINAL-RING(10-GA TO 12-GA, 5/16-IN SCREW) | |
| | 125-7875E | | TUBE-HEAT SHRINK(7.44-MM DIA)(4-CM) | |
| | 9W-2033 | [16] | TERMINAL-BLADE(14-GA TO 16-GA) | |
| | 9W-2034 | [4] | TERMINAL-BLADE(10-GA TO 12-GA) | |
| | 5P-3454 | [1] | TERMINAL-RING(4-GA, 5/16-IN SCREW) | |
| | 128-4162 | [2] | TERMINAL AS(6-GA TO 8-GA) | |
| | 5P-1478 | [2] | TERMINAL-FORK(10-GA TO 12-GA, NO. 10 SCREW) | |
| | 5P-1475 | [4] | TERMINAL-FORK(14-GA TO 16-GA, NO. 8 SCREW) | |
| | 9W-2035 | [4] | BLOCK-FUSE | |
| | 186-3735 | [24] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| | 127-5483 | [1] | PLUG AS-CONNECTOR(1-PIN) | |
| | 245-0159 | [2] | PLUG AS | |
| | 245-0164 | [1] | PLUG AS(12-PIN) | |
| | 245-8023 | [1] | PLUG AS-CONNECTOR(40-PIN) | |
| | 8T-8737 | [16] | PLUG-SEAL | |
| | 245-0165 | [1] | RECEPTACLE AS | |
| | 245-0169 | [1] | RECEPTACLE AS-CONNECTOR(12-PIN) | |
| | 245-0172 | [1] | RECEPTACLE AS | |
| | 245-8027 | [1] | RECEPTACLE AS(9-PIN) | |
| | 8N-1549 | [1] | SOCKET-CONNECTOR(4-GA) | |
| | 9W-0844 | [4] | SOCKET-CONNECTOR(14-GA TO 16-GA) | |
| | 186-3736 | [37] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | | | S/N B1R151-UP |
| | 235-2685 | [1] | PLATE AS | |
| | 6V-9632M | [4] | NUT-WELD(M6X1-THD) | |
| | 7X-7963M | [2] | BOSS-WELD(M10X1.5X100-MM) | |
| | 237-4506 | [1] | PLATE AS | |
| | 117-2311 | [1] | SOCKET-AUXILIARY POWER(12-VOLT) | |
| | 9R-7941 | [1] | SOCKET AS | |
| | 9R-7980 | [1] | COVER | |
| | | | |
| | 8T-4137M | [2] | BOLT(M10X1.5X20-MM) | |
| | 8T-4189M | [1] | BOLT(M8X1.25X20-MM) | |
| | 2S-9255 | [4] | BOLT-SOCKET HEAD(4-40X0.375-IN) | |
| | 116-0118 | [1] | CLIP | |
| | 9M-8406 | [1] | CLIP(LOOP) | |
| | 4P-8134 | [2] | CLIP(LADDER) | |
| | 6D-4246 | [1] | CLIP(LOOP) | |
| | 235-2683 | [1] | FILM(FUSE, CIRCUIT BREAKER) | |
| | 163-9433 | [1] | FILM-IDENTIFICATION(12-VOLT, 24-VOLT) | |
| | 9W-1442 | [15] | FUSE(10-AMPERE) | |
| | 9W-1446 | [1] | FUSE(20-AMPERE) | |
| | 6V-8225M | [2] | NUT(M6X1-THD) | |
| | 5C-7261M | [1] | NUT(M8X1.25-THD) | |
| | 6V-8185 | [2] | NUT(1/4-20-THD) | |
| | 128-6157 | [1] | PLATE | |
| | 166-7278 | [1] | PLATE | |
| | 202-4327 | [1] | PULLER-FUSE | |
| | 7U-4892 | [8] | SCREW(8-32X0.75-IN) | |
| | 7Y-7389M | [2] | SCREW(M5X0.8X16-MM) | |
| | 6V-5698M | [4] | SCREW-BUTTON HEAD(M4X0.7X10-MM) | |
| | 6V-9672M | [4] | SCREW-MACHINE(M4X0.7X16-MM) | |
| | 9X-2044M | [8] | SCREW-TRUSS HEAD(M6X1X16-MM) | |
| | 141-4976 | [4] | SCREW-WASHER HEAD(4-40X0.5-IN) | |
| | 3S-2093 | [3] | STRAP-CABLE | |
| | 114-6658 | [8] | WASHER(6.5X17X1-MM THK) | |
| | 8T-4224 | [3] | WASHER-HARD(8.8X16X2-MM THK) | |
| | 8T-4205 | [2] | WASHER-HARD(7.2X14.5X2-MM THK) | |
| | 8T-4121 | [2] | WASHER-HARD(11X21X2.5-MM THK) | |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
