HK50428
|
[1] |
WHEEL
|
ATT
Gathering Wheel Kit Complete
|
| 1. |
284463
|
[2] |
SPACER
|
CAS
Bushing
|
| 2. |
700117003
|
[1] |
STRUT
|
HFI
- Wheel, Left
|
| 3. |
700117013
|
[4] |
STRAP
|
HFI
- Link
|
| 4. |
700707651
|
[4] |
SPRING
|
CAS
- Compression
|
| 5. |
700117009
|
[4] |
SPACER
|
HFI
Bushing
|
| 6. |
700117011
|
[2] |
SUPPORT
|
CAS
- Chain
|
| 7. |
700116997
|
[2] |
SPINDLE
|
HFI
Bracket - Spindle
|
| 8. |
6868954
|
[2] |
RIM
|
CAS
Wheel Assembly - Gathering Superseded by part number: 700711239, 700128318
|
| 9. |
50104
|
[4] |
BEARING CUP,50.01mm OD
|
CAS
Cup - Bearing
|
| 10. |
274760
|
[2] |
7/8-14 Slotted Hex Nut
|
SEAL KIT
|
| 11. |
7705429
|
[2] |
WASHER,7/8", SAE
|
CAS
7/8 Narrow Plain Washer Superseded by part number: 87366
|
| 12. |
700708092
|
[4] |
ROLLER BEARING
|
CAS
Cone - Bearing Superseded by part number: E13994
|
| 13. |
744912
|
[2] |
SEAL
|
CAS
- Grease Superseded by part number: CAS744912
|
| 14. |
1714773
|
[4] |
PIN,1/2" x 2", Coiled
|
CAS
Superseded by part number: 138-2000
|
| 15. |
700117004
|
[1] |
SLIDE
|
HFI
Strut - Wheel, Right
|
| 16. |
8027476
|
[6] |
SEGMENT
|
CAS
Notched Segment - Rubber Superseded by part number: 700128319, 700711239
|
| 17. |
700708977
|
[2] |
SPRING
|
CAS
|
| 18. |
700119167
|
[2] |
ANGLE
|
CAS
- Bracket
|
| 19. |
700117016
|
[1] |
SUPPORT
|
CAS
- Pivot, Right
|
| 20. |
705541
|
[6] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 Hardened Plain Washer
|
| 21. |
26930
|
[2] |
CAP
|
IH
- Hub Superseded by part number: 518842R1
|
| 22. |
700117015
|
[1] |
SUPPORT
|
CAS
- Pivot, Left
|
| 23. |
80702
|
[2] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
3/8 Hardened Plain Washer
|
| . . |
702035
|
[2] |
BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5, Full Thd
|
CAS
3/8-16 x 1-1/4 C
|
| . . |
701235
|
[6] |
BOLT,1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 x 1-1/2 C
|
| . . |
7701683
|
[2] |
BOLT,Hex, 5/8" - 11 x 3", Gr 5
|
CAS
5/8-11 x 3 C Superseded by part number: 87338
|
| . . |
873562
|
[4] |
BOLT,Hex, 1/2" - 13 x 7 1/2", Gr 5
|
CAS
1/2-13 x 7-1/2 B Superseded by part number: 86505997
|
| . . |
7770175
|
[24] |
CARRIAGE BOLT,Sht Sq Nk, 1/4" - 20 x 1 1/4", Gr 5
|
CAS
1/4-20 x 1-1/4 RHSNB Superseded by part number: 111-122
|
| . . |
7883325
|
[4] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
