纽荷兰零件查询(ISM N844) - ISM ENGINE (10.001.02[01]) - CYLINDER BLOCK New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
204 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | SBA195906990 | [1] | GASKET KIT | SBAGasket |
| 2. | SBA064200025 | [2] | PLUG | NH Superseded by part number: SBA064210025 |
| 3. | SBA064210040 | [5] | CAP | NH Superseded by part number: SBA064209055 |
| 4. | SBA198466010 | [3] | PLUG | NHBlank 8.4mm |
| 5. | SBA198466020 | [4] | PLUG | NHBlank 10.4mm |
| 6. | SBA198466030 | [4] | PLUG | NHBlank 6.5 x 7mm |
| 7. | SBA165296220 | [1] | SHAFT | DUBIdler Gear Superseded by part number: SBA165296260 |
| 8. | SBA198517090 | [1] | BUSHING | DUB |
| 9. | SBA198517222 | [1] | BUSHING | AStd |
| 9. | SBA198517226 | [1] | BUSHING | DUB.1" (.25mm), U/S |
| 9. | SBA198517229 | [1] | BUSHING | DUB.2" (.5mm), U/S |
| 10. | SBA040106203 | [1] | BALL BEARING,17mm ID x 40mm OD x 12mm W | NH Superseded by part number: ST262 |
| 11. | SBA064100045 | [1] | PLUG | NHExpansion Superseded by part number: 47748684 |
| 12. | SBA042309018 | [1] | NEEDLE BEARING | NH |
| 13. | SBA042309017 | [1] | NEEDLE BEARING | NH |
| 14. | SBA030500612 | [2] | DOWEL | NH |
| 15. | SBA030500616 | [2] | DOWEL,M6 x 16 | NH |
| 16. | SBA030501025 | [2] | BALL STUD,M10 x 25 L | NHBALL PIN |
| 17. | SBA030309005 | [2] | PIN | NHSpring |
| 18. | SBA012110820 | [3] | STUD | NH |
| 19. | SBA012110635 | [1] | STUD | NH |
| 20. | SBA012110660 | [1] | STUD | NH |
| 21. | SBA110996860 | [1] | GASKET | NHOil Pan Gasket |
| 22. | SBA198636170 | [1] | SEAL | NHRear Main |
| 23. | SBA064500060 | [1] | PLUG | WICPlug |
| 24. | SBA140546020 | [1] | ADAPTER | NHJoint |
| 25. | 84475542 | [1] | ENGINE OIL FILTER | RACMain |
| 26. | SBA120116100 | [8] | TAPPET | DUB |
| 27. | SBA120456250 | [8] | PUSH ROD | NH |
| 28. | SBA140036220 | [1] | PRESSURE RELIEF VALVE | NH |
| 29. | SBA052109078 | [1] | O-RING,2.4mm Thk x 14.8mm ID | NH |
| 30. | SBA064409006 | [1] | PLUG,1/8" NPT | NH |
