卡特零件查询（725） 354-0048: HARNESS AS-ENGINE
广数供应链运营团队, 14 02月, 2025，浏览：
762 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| | 211-6807 | [1] | COVER-CONNECTOR | |
| | 155-2270 | [1] | KIT-CONNECTING PLUG(2-PIN) | |
| | 155-2255 | [1] | KIT-CONNECTING PLUG(12-PIN) | |
| | 155-2265 | [1] | KIT-CONNECTING PLUG(8-PIN) | |
| | | | (EACH PLUG KIT INCLUDES PLUG AS, WEDGE, & INTERFACE SEAL) |
| | 102-8802 | [1] | KIT-RECEPTACLE(2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 105-1797 | [1] | MOUNT | |
| | 230-4011 | [4] | PLUG AS-CONNECTOR(2-PIN) | |
| | | | (EACH INCLUDES) |
| | 264-7029 | [1] | SEAL-CONNECTOR | |
| | 230-4013 | [1] | PLUG AS-CONNECTOR(3-PIN) | |
| | 264-7030 | [1] | SEAL-CONNECTOR | |
| | 237-0227 | [2] | PLUG AS-CONNECTOR(3-PIN) | |
| | | | (EACH INCLUDES) |
| | 264-7030 | [1] | SEAL-CONNECTOR | |
| | 264-5732 | [1] | PLUG AS-CONNECTOR(120-PIN) | |
| | 288-7324 | [1] | SEAL-CONNECTOR | |
| | 8T-8737 | [93] | PLUG-SEAL | |
| | 126-1768 | [68] | SOCKET-CONNECTOR(14-GA TO 16-GA) | |
| | | | -OR- |
| | 9X-3402 | [68] | SOCKET-CONNECTOR(16-GA TO 18-GA) | |
| | 3S-2093 | [2] | STRAP-CABLE | |
| | 125-7875E | | TUBE-HEAT SHRINK(7.44-MM DIA)(15-CM) | |
| | E | | ORDER BY THE CENTIMETER |
