神钢零件查询(6D14-T) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (01-007) - FLYWHEEL HOUSING Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
749 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-6. | VAME070243 | [1] | FLYWHEEL HOUSING ASSY | |
| 1. | VAME070244 | [1] | HOUSING,FLYWHEEL | |
| 3. | VAMF407038 | [1] | STUD,FOR STARTER 12X45 | |
| 5. | VAME031062 | [1] | POINTER | KOBPOINTER |
| 6. | VAMF350047 | [1] | SCREW | KOBSCREW,W/WSR 5X10 |
| 9. | VAME020359 | [1] | PLUG | KOBPLUG,DUST Superseded by part number: VAME609555 |
| 9A. | VAME030870 | [1] | CAP | KOBCAP,SEALING |
| 10. | VAMF665007 | [1] | SCREW | KOB20 |
| . . | VAMF660068 | [1] | PACKING | KOBGASKET 20 Superseded by part number: VAF420220000 |
| 11. | VAMH000723 | [8] | BOLT | KOBBOLT,FLANGE 10X70 |
| 12. | VAMH000716 | [5] | BOLT | KOBBOLT,FLANGE 10X55 |
| 13. | VAMH000712 | [1] | SCREW | KOBBOLT,FLANGE 10X65 |
| 14. | VAMH000709 | [1] | BOLT | KOBBOLT,FLANGE 10X50 |
| 16. | VAME030856 | [1] | OIL SEAL | KOBOILSEAL,RE |
| 17. | VAME030873 | [1] | PLATE | KOBRETAINER,OILSEAL |
| 19. | VAME030857 | [1] | SEAL | KOBSLINGER.OILSEAL RE |
| 20. | VAMF241253 | [5] | SCREW | KOBBOLT,W/WSR SX20 |
| 24. | VAME031480 | [1] | FRONT PLATE | KOBPLATE,RE Superseded by part number: VAME071270 |
