纽荷兰零件查询(ISM N844) - ISM ENGINE (10.103.02) - FLYWHEEL, BELL HOUSING & STARTER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
550 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | SBA110447780 | [1] | FLYWHEEL | WICCover |
| 2. | SBA011510820 | [10] | CAPTIVE WASHER SCREW,Hex, M8 x 20, G5 | NH |
| 3. | SBA185086530 | [1] | STARTER MOTOR | NH Superseded by part number: SBA185086750 |
| 3. | SBA185086530GV | [1] | STARTER MOTOR | RACValue Superseded by part number: SBA185086551GV |
| 3. | SBA185086530R | [1] | REMAN-STARTER | NHReman for New PN SBA185086530 |
| 3. | SBA185086530C | [1] | CORE-STARTER | NHReturn Number |
| 4. | 43140 | [2] | BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8 | NH |
| 5. | SBA026200010 | [2] | WASHER | NH |
| 6. | 140028 | [2] | WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk | NH |
| 7. | SBA010109341 | [6] | BOLT | NH |
| 8. | SBA185736260 | [1] | COVER | DUB |
| 9. | SBA115357570 | [1] | ENGINE FLYWHEEL | SBAIncl. 10 |
| 10. | SBA115376040 | [1] | RING GEAR | NH |
