凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (049) - REGULATOR, FLOW, HYDRAULIC, THREADER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
930 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700707258
|
[1] |
GOVERNOR
|
IH
Regulator Flow - Hydraulic Threader, Complete
|
| 2. |
700707839
|
[1] |
VALVE
|
IH
Check Valve - Poppet, Assembly
|
| 3. |
700707838
|
[1] |
SPOOL
|
L
Assembly
|
| 4. |
700707837
|
[1] |
VALVE
|
L
Knob - Adjustment, Flow Control, Assembly
|
| 5. |
700707840
|
[2] |
PLUG
|
HFI
Assembly
|
| 6. |
700706154
|
[2] |
SEAL KIT
|
L
O-Ring and Seal Repair Kit Superseded by part number: 86508168
|
| 7. |
700707843
|
[1] |
SEAL KIT
|
IH
O-Ring and Seal Repair Kit
|
