纽荷兰零件查询(ISM N844) - ISM ENGINE (10.202.01[04]) - AIR CLEANER INLET New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
590 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 82012728 | [1] | COLLAR,50mm - 65mm, Worm Gear | NH Superseded by part number: 82036462 |
| 2. | 86515783 | [1] | HOSE,57.10 mm ID x 283.00 mm, SAE J200 BC, SAE J200 CA | BEL48.34" Long |
| 2. | 86557319 | [1] | HOSE,57.10 mm ID x 388.10 mm, SAE J200-BC 710/SAE J200-CA 710 | BEL41.35" Long |
| 3. | 801895 | [1] | CABLE TIE,30.63" | NHCABLE STRAP Cable Tie Superseded by part number: 529070 |
| 4. | 86522009 | [1] | CLAMP | BELHose, 3" |
| 5. | 9706689 | [1] | BOLT,Hex, 3/8" - 16 x 1 3/4", Gr 5 | PAIf Used |
| 5. | 88206 | [1] | BOLT,Hex, 3/8" - 16 x 1", Gr 5 | NHIf Used |
| 6. | 80702 | [1-3] | WASHER,0.44" ID x 1" OD x 0.08" Thk | NH |
| 7. | 9628503 | [1] | NUT,3/8"-16, G5 | NH |
| 8. | 86597134 | [1] | BRACKET | BELIf Used Superseded by part number: 86501211 |
| 8. | 87032047 | [1] | BRACKET | WICIf Used, Start Serial: LMU013613 |
| 8. | 86501211 | [1] | BRACKET | BELIf Used |
| 8A. | 120104 | [2] | BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8 | NHHardware For Mounting Bracket, Ref 8 |
| 8B. | 80681 | [4] | BEARING WASHER,5/16" | NHHardware For Mounting Bracket, Ref 8 Superseded by part number: 83990583 |
| 9. | 140045 | [1] | BELLEVILLE WASHER,M10X22 ZNM | NH |
