纽荷兰零件查询(ISM N844) - ISM ENGINE (10.220.02[02]) - FOOT THROTTLE KIT New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
282 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87576179 | [1] | DIA KIT, ADDITIONAL PRODUCTS | WICFoot Throttle Kit; Incl. 2 - 23 and Instructions |
| 2. | 87535988 | [1] | PEDAL | WICFoot Throttle; Replaces 87397667 |
| 3. | 87578956 | [1] | TUBE SPACER,19.9mm ID x 25.4mm OD x 20.6mm L | WIC |
| 4. | 9635082 | [8] | NUT,5/16"-18, G5 | NH |
| 5. | 322358 | [8] | BELLEVILLE WASHER,M8 x 18mm OD x 1.4mm Thk | NH |
| 6. | 280327 | [8] | CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5, Full Thd | NH |
| 7. | 86567251 | [3] | FLANGED BEARING,19mm ID | BELSide |
| 8. | 87550553 | [1] | PEDAL | WIC |
| 9. | 87584298 | [1] | BRACKET | WICCable Mount; Replaces 87550552 |
| 10. | 80681 | [2] | BEARING WASHER,5/16" | NH Superseded by part number: 83990583 |
| 11. | 87343998 | [2] | LOCK NUT | SASNut |
| 12. | 9635884 | [2] | BOLT,Hex, 5/16" - 18 1", Full Thd, Gr 5 | NH |
| 13. | 87548418 | [1] | CABLE,1778mm L | WICFoot Throttle |
| 14. | 86603720 | [2] | BALL JOINT HEAD,#10 - 32 | WIC |
| 15. | 87548416 | [1] | PEDAL | WICLinkage, Foot Throttle |
| 16. | 38-11216 | [1] | LOCK PIN,3/16" x 1", Slotted | CASPin Superseded by part number: 118827 |
| 17. | 87550545 | [1] | SPRING | WICFoot Throttle |
| 18. | 87550544 | [1] | PEDAL | WICLink, Foot Throttle |
| 19. | 291308 | [1] | SEALING STRIP,0.75" W x 0.5" Thick | BEL12 in. Required |
| 20. | 87557968 | [1] | BRACKET | WICRH |
| 21. | 86625263 | [4] | WASHER,9mm ID x 20mm OD x 1.6mm Thk | ZED |
| 22. | 87550550 | [1] | TUBE,12.6 mm ID x 15.9 mm OD x 402.4, 253.9 mm L | WICTube, Bucket; Replaces 87050213 On Fig. 35.204.04, Ref. 20 |
| 23. | 87550551 | [1] | TUBE,12.6 mm ID x 15.9 mm OD x 498.2, 413.8 mm L | WICTube, Bucket; Replaces 87050214 On Fig. 35.204.04, Ref. 18 |
