纽荷兰零件查询(ISM N844) - ISM ENGINE (55.301.02) - ALTERNATOR MOUNTING New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
460 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | SBA185727000 | [1] | PLATE | NHAdjusting |
| 2. | 84281043 | [1] | ALTERNATOR,12V, 120A, W/ Pulley | WIC |
| 2. | 84281043R | [1] | REMAN-ALTERNATOR | WIC |
| 2. | 84281043C | [1] | CORE-ALTERNATOR | WICReturn Number |
| 3. | SBA011510825 | [2] | CAPTIVE WASHER SCREW,Hex, M8 x 25, G5 | NH |
| 4. | SBA026109017 | [1] | WASHER | NH |
| 5. | 84367403 | [1] | BRACKET | WIC Superseded by part number: 84580649 |
| 6. | SBA011510816 | [3] | BOLT | NH |
| 7. | SBA010311035 | [2] | BOLT,M10 x 35 | DUB Superseded by part number: 9706704 |
| 8. | 825-11410 | [2] | NUT,M10 x 1.25, Cl 8 | CAS Superseded by part number: 18711611 |
| 9. | 47396937 | [1] | BELT,V-Belt, 978mm Nominal | WIC |
