沃尔沃零件查询5350 Lubricating oil system5350 NoneNoneNoneAutodata Volvo online
广数供应链运营团队, 14 02月, 2025，浏览：
774 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 5. |
VOE7421025
|
[0001] |
Gasket
|
|
| 50. |
VOE945467
|
[0001] |
Lock nut
|
|
| 51. |
VOE4771429
|
[0001] |
Attaching Plate
|
|
| 52. |
VOE13941907
|
[0002] |
Washer
|
|
| 53. |
VOE13955523
|
[0002] |
Screw
|
|
| 54. |
VOE941950
|
[0001] |
Clamp
|
|
| 55. |
VOE13955894
|
[0002] |
Washer
|
|
| 56. |
VOE945467
|
[0002] |
Lock nut
|
|
| 57. |
VOE4771000
|
[0001] |
Clamp
|
|
| 58. |
VOE466631
|
[0001] |
Housing
|
|
| 59. |
VOE13949656
|
[0001] |
O-ring
|
|
| 6. |
VOE13947628
|
[0001] |
Plane gasket
|
|
| 60. |
VOE13960171
|
[0001] |
O-ring
|
|
| 61. |
VOE13942336
|
[0003] |
Spring washer
|
|
| 62. |
VOE13940115
|
[0003] |
Screw
|
|
| 63. |
VOE466623
|
[0001] |
Nipple
|
|
| 64. |
VOE21707134
|
[0001] |
Oil Filter
|
|
| 65. |
VOE469846
|
[0001] |
Sealing ring
|
|
| 66. |
VOE469331
|
[0001] |
Seat
|
|
| 67. |
VOE471085
|
[0001] |
Valve cone
|
|
| 68. |
VOE470291
|
[0001] |
Spring
|
|
| 69. |
VOE466445
|
[0001] |
Compression spring
|
|
| 7. |
VOE942352
|
[1] |
Plug
|
|
| 70. |
VOE13949721
|
[0001] |
O-ring
|
|
| 71. |
VOE469465
|
[0001] |
Cover
|
|
| 72. |
VOE955512
|
[0002] |
Hexagon screw
|
|
| 73. |
VOE13941906
|
[0002] |
Washer
|
|
| 8. |
VOE13941907
|
[35] |
Washer
|
|
| 9. |
VOE940186
|
[35] |
Hexagon screw
|
|
| 1. |
VOE4774185
|
[0001] |
Oil pump
|
|
| 10. |
VOE4771188
|
[1] |
Baffle plate
|
|
| 11. |
VOE11030585
|
[1] |
Gasket
|
|
| 12. |
VOE13941907
|
[9] |
Washer
|
|
| 13. |
VOE13955523
|
[9] |
Screw
|
|
| 14. |
VOE964114
|
[1] |
O-ring
|
|
| 15. |
VOE13963978
|
[1] |
Nipple
|
|
| 16. |
VOE956970
|
[1] |
Ferrule
|
|
| 17. |
VOE956984
|
[1] |
Fitting nut
|
|
| 18. |
VOE4771003
|
[1] |
Oil pipe
|
|
| 19. |
VOE955982
|
[1] |
O-ring
|
|
| 2. |
VOE421404
|
[0001] |
Baffle
|
|
| 20. |
VOE4771198
|
[1] |
Dipstick
|
|
| 21. |
VOE955082
|
[0001] |
Cap plug
|
|
| 22. |
VOE13949657
|
[0001] |
O-ring
|
|
| 23. |
VOE4770988
|
[0001] |
Housing
|
|
| 24. |
VOE13941907
|
[0002] |
Washer
|
|
| 25. |
VOE955526
|
[0002] |
Hexagon screw
|
|
| 26. |
VOE466905
|
[0002] |
Fitting
|
|
| 27. |
VOE4771002
|
[0001] |
Delivery pipe
|
|
| 28. |
VOE466906
|
[0002] |
Fitting
|
|
| 29. |
VOE4771001
|
[0001] |
Delivery pipe
|
|
| 3. |
VOE955538
|
[0004] |
Hexagon screw
|
|
| 30. |
VOE469482
|
[0001] |
Sealing ring
|
|
| 31. |
VOE4770978
|
[0001] |
Strainer
|
|
| 32. |
VOE13941907
|
[0002] |
Washer
|
|
| 33. |
VOE955526
|
[0002] |
Hexagon screw
|
|
| 34. |
VOE414621
|
[0001] |
Wire gauze
|
|
| 35. |
VOE118125
|
[0001] |
Snap ring
|
|
| 36. |
VOE13949721
|
[0001] |
O-ring
|
|
| 37. |
VOE943336
|
[0002] |
Stud
|
|
| 38. |
VOE13955894
|
[0002] |
Washer
|
|
| 39. |
VOE945467
|
[0002] |
Lock nut
|
|
| 4. |
VOE4770958
|
[0001] |
Oil pan
|
|
| 40. |
VOE4770992
|
[0001] |
Strainer
|
|
| 41. |
VOE414621
|
[0001] |
Wire gauze
|
|
| 42. |
VOE118125
|
[0001] |
Snap ring
|
|
| 43. |
VOE13941907
|
[0004] |
Washer
|
|
| 44. |
VOE13955523
|
[0004] |
Screw
|
|
| 45. |
VOE4770997
|
[0001] |
Anchorage
|
|
| 46. |
VOE13941907
|
[0004] |
Washer
|
|
| 47. |
VOE7192548
|
[0002] |
Screw
|
|
| 48. |
VOE13955894
|
[0001] |
Washer
|
|
| 49. |
VOE942402
|
[0001] |
Flange screw
|
|
