卡特零件查询（725） 314-9000: CAMERA GP
广数供应链运营团队, 14 02月, 2025，浏览：
603 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| | 251-4138Y | [1] | DISPLAY GP-CAMERA(WORK AREA VISUAL SYSTEM) | |
| | | | |
| | 251-4160J | [1] | CAMERA GP(115-DEG, COLOR) | |
| | | | |
| | 251-8248 | [1] | CABLE AS-COMMUNICATION | |
| | 261-3223 | [1] | CABLE AS-COMMUNICATION | |
| | | | |
| | 8T-4179M | [1] | BOLT(M12X1.75X20-MM) | |
| | 5P-8525 | [1] | GROMMET | |
| | 8T-4244M | [1] | NUT(M12X1.75-THD) | |
| | 293-8602 | [1] | PLATE | |
| | 9X-2043M | [4] | SCREW-TRUSS HEAD(M6X1X14-MM) | |
| | 3S-2093 | [27] | STRAP-CABLE | |
| | 8T-4223 | [2] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| | | | |
| | | | AVAILABLE REPAIR KIT(S): |
| | 251-4162J | [1] | KIT-BRACKET(CAMERA) | |
| | | | (INCLUDES BRACKET, BOLTS, LOCK NUTS, BOLT-SOCKETS, GASKET & ALLENKEY) |
| | J | | KIT MARKED J SERVICES PART(S) MARKED J |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
