凯斯零件查询(8450) - CASE IH ROUND BALER (1/88-12/93) (060) - SHIELDS, SIDE, ASSBEMBLY Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
613 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700117070
|
[1] |
SHIELD
|
CAS
- Left, Rear
|
| 2. |
700116002
|
[1] |
DOOR
|
CAS
- Left
|
| 3. |
7025075
|
[2] |
BRACKET
|
CAS
- Hook
|
| 4. |
700115984
|
[4] |
HINGE
|
HFI
- Door
|
| 5. |
700117082
|
[2] |
SUPPORT
|
HFI
|
| 6. |
700115991
|
[1] |
SUPPORT
|
HFI
- Jack
|
| 7. |
700117071
|
[1] |
PANEL
|
CAS
- Left, Front
|
| 8. |
776682
|
[2] |
HOOK
|
CAS
- Rubber Superseded by part number: 86975220
|
| 9. |
776674
|
[2] |
SUPPORT
|
L
Anchor - Hook
|
| 10. |
63784
|
[2] |
CLEVIS PIN
|
IH
1/4 x 1-1/2 Clevis Superseded by part number: 141-13
|
| 11. |
700115977
|
[1] |
STRAP
|
HFI
- Corner
|
| 12. |
62349
|
[2] |
LOCK WASHER
|
NNA
.149 Hairpin Cotter Superseded by part number: 87790435, 87790435, 9966809, 87790435, 9966809, S120261
|
| 13. |
700116001
|
[1] |
STRAP
|
HFI
- Brace
|
| 14. |
700117079
|
[2] |
LATCH
|
HFI
- Lower
|
| 15. |
700117080
|
[2] |
CHANNEL
|
HFI
- Reinforcement
|
| 16. |
700117081
|
[4] |
SPACER
|
HFI
|
| 17. |
700116003
|
[1] |
DOOR
|
CAS
- Right
|
| 18. |
700116028
|
[2] |
SUPPORT
|
HFI
- Door
|
| 19. |
763565
|
[2] |
PIN
|
CAS
5/16 x 2 Clevis Pin Superseded by part number: 439-5532
|
| 20. |
700117078
|
[2] |
SUPPORT
|
CAS
Rod - Detent
|
| 21. |
754606
|
[2] |
SPRING
|
CAS
- Compression
|
| 22. |
705525
|
[2] |
WASHER
|
CAS
5/16 Hardened Plain Washer Superseded by part number: 86637953
|
| 23. |
700117083
|
[2] |
STRAP
|
HFI
- Brace
|
| 24. |
700117074
|
[1] |
SHIELD
|
HFI
- Right, Rear Superseded by part number: 700131973
|
| 25. |
700115999
|
[3] |
SUPPORT
|
HFI
- Shield
|
| 26. |
700114084
|
[2] |
STRAP
|
HFI
|
| 27. |
700117075
|
[1] |
SUPPORT
|
HFI
- Shield
|
| 28. |
700116000
|
[1] |
STRAP
|
HFI
- Left
|
| 29. |
700115986
|
[4] |
HINGE
|
HFI
- Shield, Rear
|
| . . |
7883325
|
[61] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 x 3/4 HWHMS Superseded by part number: 121-115
|
| . . |
7883333
|
[2] |
BOLT,Hex, 5/16" - 18 x 1", Gr 120M
|
CAS
5/16-18 x 1 HWHMS Superseded by part number: 121-108
|
| . . |
7883358
|
[4] |
SCREW,Hex Washer, 5/16" - 18 x 1 1/2"
|
CAS
5/16-18 x 1-1/2 HWHMS Superseded by part number: 163-56
|
| . . |
700704837
|
[4] |
SCREW,Cross Pan Hd, #10-24 x 3/8"
|
CAS
No. 10-24 x 3/8 CRPHMS Superseded by part number: 72181877
|
| . . |
NLS
|
[4] |
NO LONGER SERVICED
|
BAS
No. 10-24 H
|
