纽荷兰零件查询(F3DFA613B E003) - ENGINE 504384985 - 84250911 W/BRAKE (10.206.02) - FILTER ENGINE OIL - SUPPORT (5801415506) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
924 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 5801415490 | [1] | | FILTER |
| 2. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 4. | 5801415498 | [1] | | GASKET |
| 5. | 84572228 | [1] | ELEMENT | RAC |
| 6. | 16586725 | [1] | BOLT,Hex, M8 x 1.25 x 40mm | TORM8 x 40 |
| 7. | 16592425 | [5] | BOLT,M8 x 65mm | TOR |
| 8. | 16992511 | [1] | PLUG | TOR Superseded by part number: 10300814 |
| 9. | 5167640 | [1] | SEALING WASHER,14.09mm ID x 26.45mm OD x 1.5mm Thk | BAS |
