神钢零件查询(6D14-T) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (02-003) - WATER PIPE & THERMOSTAT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
324 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-2. | VAME035272 | [1] | CASE | KOBTHERMOSTAT CASE ASSY |
| 1. | VAME035279 | [1] | CASE | KOBCASE,THERMOSTAT |
| 1A. | VAMS661124 | [1] | PLUG,TAPER PT3/4 | |
| 2. | VAME035254 | [1] | UNIVERSAL JOINT | KOBJOINT,BY-PASS |
| 3-4. | VAME999569 | [1] | THERMO KIT THERMOSTAT KIT 76.5\u00b0C (FOR SERVICE ONLY) | THERMO KIT THERMOSTAT KIT 76.5°C (FOR SERVICE ONLY) |
| 3. | VAME035100 | [1] | GASKET | KOBGASKET Superseded by part number: VAME303375 |
| 4. | VAME038850 | [1] | THERMOSTAT | KOBTHERMOSTAT 76.5°C Superseded by part number: VAME994514 |
| 5. | VAME039575 | [1] | COVER | KOBCOVER,THERMOSTAT |
| 6. | VAMF140227 | [3] | FLANGE BOLT | KOBBOLT,FLANGE 8X25 |
| 7. | VA3124618702 | [2] | PLUG | KOB Superseded by part number: 240292A1 |
| 8. | VAME031082 | [1] | GASKET | KOBGASKET,HANGER Superseded by part number: VAME074770 |
| 9. | VAMH000517 | [2] | BOLT | KOBBOLT,SEAL 10X30 |
| 9. | VAMH000537 | [2] | BOLT | KOBBOLT,SEAL 10X105 |
