纽荷兰零件查询(F3DFA613B E003) - ENGINE 504384985 - 84250911 W/BRAKE (10.250.03[03]) - TURBOBLOWER PIPES (504386760) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
759 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 17765694 | [2] | CLIP | CLIP |
| 2. | 504382418 | [1] | | RUBBER SLEEVE |
| 3. | 17765291 | [4] | CLIP | CLIP |
| 4. | 504382419 | [1] | | RUBBER SLEEVE |
| 5. | 504388469 | [1] | | AIR DUCT |
| 6. | NSS | [1] | NOT SERVICED SEPARATELY | CONASSY Contains Ref.3, 9 |
| 7. | 16587824 | [2] | BOLT,Hex, M10 x 1.5 x 60mm | TORM10 x 60 |
| 8. | 16586225 | [4] | BOLT,M8 x 16mm | TOR |
| 9. | 504382424 | [1] | | RUBBER SLEEVE |
