HK50563
|
[1] |
BALE CHAMBER
|
ATT
Kit - Bale Ejector, Complete (Includes Pages 128 thru 137)
|
| 1. |
700708068
|
[2] |
CLEVIS PIN,15.77mm OD x 68.66mm L
|
IH
5/8 x 2-1/2
|
| 2. |
700118714
|
[1] |
STRUT
|
HFI
- Kicker, Left
|
| 3. |
700115818
|
[1] |
TUBE,60.32 mm OD, 1484 mm Length
|
CAS
Pipe - Cross
|
| 4. |
700119843
|
[1] |
ROLLER
|
HFI
- Ejector
|
| 5. |
61-35052
|
[4] |
HEX SOC SCREW,1/2"-13 x 3 1/4"
|
CAS
1/2-13 x 3-1/4 HSHCS
|
| 6. |
700118715
|
[1] |
STRUT
|
HFI
- Kicker, Right (S.N. CFH0015001 thru 0015766) Sub. 700122477 Strut, 700122757 Support and No 6-32 x 3/4 CRPHMS, LHSN, P(2) Superseded by part number: 700122477, 700122729
|
| 6. |
700122477
|
[1] |
STRUT
|
HFI
- Kicker, Right (S.N. CFH0015767 and on)
|
| 7. |
763227
|
[2] |
BRACKET
|
CAS
5/8 x 3 Clevis Pin Superseded by part number: 51200161, 51200161, NLS
|
| 8. |
700118987
|
[1] |
SHIELD
|
HFI
- Switch (S.N. CFH0015001 thru 0015766)
|
| 9. |
700107049
|
[1] |
SPACER
|
HFI
(S.N. CFH0015001 thru 0015766)
|
| 10. |
700118986
|
[1] |
SUPPORT
|
HFI
- Switch (S.N. CFH0015001 thru 0015766)
|
| 11. |
705525
|
[1] |
WASHER
|
CAS
5/16 Hardened Plain Washer Superseded by part number: 86637953
|
| 12. |
705541
|
[1] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 Hardened Plain Washer
|
| 13. |
6181002
|
[1] |
SPACER
|
CAS
|
| 14. |
700710189
|
[2] |
LOCK NUT
|
CAS
No. 6-32 x 3/4 LHSN - Stainless Steel (S.N. CFH0015767 and on)
|
| 15. |
700710187
|
[2] |
WASHER
|
CAS
No. 6 P - Stainless Steel (S.N. CFH0015767 and on)
|
| 16. |
700710188
|
[2] |
SCREW
|
CAS
No. 6-32 x 3/4 CRPHMS - Stainless Steel (S.N. CFH0015767 and on)
|
| 17. |
700122574
|
[1] |
SUPPORT
|
CAS
- Actuator (S.N. CFH0015767 and on)
|
| 18. |
700115943
|
[2] |
TUBE,25.4 mm OD, 61 mm Length
|
CAS
Bushing
|
| 19. |
77032
|
[2] |
FITTING
|
CAS
1/4-28 Zerk Superseded by part number: 88775
|
| 20. |
NLS
|
[4] |
NO LONGER SERVICED
|
BAS
5/8 Hardened Plain Washer
|
| . . |
7701568
|
[2] |
BOLT,Hex, 5/16" - 18 x 1 1/4", Gr 5
|
CAS
5/16-18 x 1-1/4 C Superseded by part number: 413-520
|
| . . |
413-532
|
[1] |
BOLT,Hex, 5/16" - 18 x 2", Gr 5
|
CAS
5/16-18 x 2 C Superseded by part number: 9636711
|
| . . |
7701600
|
[1] |
BOLT,Hex, 1/2" - 13 x 3 3/4", Gr 5
|
CAS
1/2-13 x 3-3/4 C Superseded by part number: 86505992
|
| . . |
873471
|
[1] |
BOLT
|
CAS
1/2-13 x 4-3/4 C Superseded by part number: 280376
|
| . . |
7883333
|
[2] |
BOLT,Hex, 5/16" - 18 x 1", Gr 120M
|
CAS
5/16-18 x 1 HWHMS Superseded by part number: 121-108
|
| . . |
704163
|
[2] |
LOCK NUT
|
CAS
5/16-18 HTLN Superseded by part number: 230-4145
|
| . . |
704858
|
[4] |
LOCK NUT
|
CAS
1/2-13 HTLN Superseded by part number: 230-4118
|
