神钢零件查询(6D14-T) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (02-015) - OIL LINE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
264 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-4. | VAME034545 | [1] | INTAKE VALVE GUIDE | KOBVALVE ASSY Superseded by part number: VAME074455 |
| 1. | VAME034546 | [1] | VALVE BODY,VALVE | VALVE BODY,VALVE |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONVALVE,RELIEF |
| 3. | VAME034548 | [1] | SPRING | KOBSPRING,RELIEF/V |
| 4. | VAMF522207 | [1] | RING | KOBRING,SNAP 16 |
| 5. | VAMF660071 | [1] | PACKING | KOBGASKET 27 |
| 6. | VAMH035129 | [1] | O-RING | KOBO-RING |
| 7. | VAME037718 | [1] | TUBE | KOBPIPE,OIL,FOR I/P.A/COMR, FOR M0,M1,M3 ONLY |
| 7. | VAME034352 | [1] | PIPE,OIL,FOR I/P.A/COMR, FOR M6 ONLY | |
| 9. | VA3007554900 | [2] | CLAMP | KOBCLAMP |
| 10. | VAMH022205 | [2] | PROTECTOR | KOBPROTECTOR |
| 11. | VAMF241227 | [2] | BOLT | KOBBOLT,W/WSR 6X20, FOR M0,M1,M3 ONLY |
| 12. | VAMH000119 | [1] | BOLT | KOBBOLT,JOINT |
| 13. | VAMF660063 | [4] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 14. | VAME034051 | [1] | HYD CONNECTOR | KOBCONNECTOR |
| 15. | VAME930307 | [1] | STAY STAY, FOR M0 ONLY | STAY STAY, FOR M0 ONLY |
| 15. | VAME034358 | [1] | STAY, FOR M6 ONLY | |
| 16. | VAMH037135 | [1] | PLUG PLUG,TAPER,FOR M1 ONLY | PLUG PLUG,TAPER,FOR M1 ONLY |
| 16A. | VAMS666222 | [1] | PLUG | SMPLUG,TAPER PT3/8, FOR M0,M1,M3 ONLY |
| I6A. | VAMS666222 | [1] | PLUG | SMPLUG,TAPER PT3/8, FOR M6 ONLY |
