神钢零件查询(6D14-T) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (04-003) - STARTER (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
846 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-25. | VAME037636 | [1] | STARTER MOTOR | KOBSTARTER ASSY 24V-4.5KW Superseded by part number: VAME077407 |
| 1. | VAME700050 | [1] | SCREW SCREW SET | SCREW SCREW SET |
| 2. | VAME700539 | [1] | BRACKET | KOBBRACKET ASSY,FR |
| 2A. | VAME700540 | [1] | BEARING SET | KOBSLEEVE BEARING SET |
| 4. | VAME700032 | [1] | LEVER | KOBLEVER ASSY |
| 5. | VAME700033 | [1] | PACKING PACKING | PACKING PACKING |
| 6. | VAME700034 | [1] | BRACKET BRACKET ASSY,CTR | BRACKET BRACKET ASSY,CTR |
| 7. | VAME700035 | [1] | SWITCH | KOBSWITCH ASSY Superseded by part number: VAM371X20672 |
| 9-11. | VAME700037 | [1] | ARMATURE | KOBARMATURE ASSY Superseded by part number: VAM106X29171 |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONARMATURE |
| 10. | VAME700038 | [1] | BEARING | KOBBEARING Superseded by part number: 135040A1 |
| 11. | VAME700039 | [1] | BEARING | KOBBEARING Superseded by part number: VAS930P28001 |
| 12. | VAME700036 | [1] | BOLT | KOBBOLT SET Superseded by part number: VAM901X01771 |
| 14-18. | VAME700040 | [1] | SHAFT | KOBCLUTCH SET SHAFT ASSY |
| 14-17. | VAME700041 | [1] | GEAR GEAR SET | GEAR GEAR SET |
| 14-15. | VAME700044 | [1] | SET OF PINIONS | KOBPINION SET |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONPINION |
| 15. | VAME700124 | [1] | STOP | KOBSTOPPER SET Superseded by part number: VAM385X03771 |
| 16. | VAME700043 | [1] | DRIVEN GEAR | KOBGEAR |
| 17. | VAME700042 | [1] | SHAFT | KOBPINION SHAFT ASSY |
| 18. | VAME700045 | [1] | COVER SET COVER SET | COVER SET COVER SET |
| 20. | VAME700049 | [2] | PACKING PACKING | PACKING PACKING |
| 21. | VAME700046 | [1] | YOKE | KOBYOKE.ASSY. |
| 22-23. | VAME700047 | [1] | HOLDER BRUSH HOLDER ASSY | HOLDER BRUSH HOLDER ASSY |
| 22. | NSS | [1] | NOT SOLD SEPARAT | CONHOLDER,BRUSH |
| 23. | VAMD607462 | [4] | SPRING SPRING,BRUSH | SPRING SPRING,BRUSH |
| 24. | VAME700048 | [1] | U-BRACKET | KOBBRACKET,RE Superseded by part number: 135050A1 |
| 25. | VAME700026 | [2] | SEAL RETAINER | KOBRING,RUBBER Superseded by part number: 135064A1 |
