神钢零件查询(6D14-T) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (04-008) - ALTERNATOR (INNER PARTS) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
799 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-26B. | VAME067617 | [1] | ALTERNATOR | KOBALTERNATOR ASSY 24V-40A |
| 1. | VAME700141 | [1] | NUT SET | |
| 2. | VAME700156 | [1] | PULLEY ASSY BX2 | |
| 3. | VAMM502365 | [1] | SCREW SET | |
| 4-6. | VAME700536 | [1] | BRACKET. ASSY FR | |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONBRACKET.FR |
| 5. | VAME700144 | [1] | SCREW SET | |
| 6. | VAME700535 | [1] | BEARING | KOBBEARING #6305 Superseded by part number: VAS930P37201, VAS930P37270 |
| 7-8. | VAME700164 | [1] | ROTOR ASSY | |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONROTOR |
| 8. | VAMD602352 | [1] | BEARING | KOBBEARING Superseded by part number: VAS930P33970 |
| 13. | VAME700159 | [1] | STATOR | |
| 14-19. | VAME700165 | [1] | BRACKET ASSY,RE | |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONBRACKET,RE |
| 15A. | VAME700087 | [1] | TERMINAL SET | |
| 16. | VAMD602826 | [1] | MOLD | |
| 16A. | VAME700161 | [1] | CONNECTION | |
| 16B. | VAMD602674 | [1] | SCREW,P 5X8 | |
| 17. | VAME700088 | [1] | SCREW SET | |
| 19. | VAME700167 | [1] | RECTIFIER ASSY | |
| 20-22. | VAME700091 | [1] | REGULATOR | KOBREGULATOR ASSY Superseded by part number: VAA866T01070, 77269893 |
| 20. | NSS | [1] | NOT SOLD SEPARAT | CONREGULATOR |
| 21. | VAMM502377 | [2] | BRUSH | KOBBRUSH |
| 22. | VAMM502378 | [2] | SPRING SPRING,BRUSH | SPRING SPRING,BRUSH |
| 26. | VAME700163 | [1] | COVER | |
| . . | VAME700100 | [2] | SCREW,W/WSR 5X12 | |
| 26B. | VAME700154 | [1] | BOLT BOLT,W/WSR 6X12 | BOLT BOLT,W/WSR 6X12 |
