神钢零件查询(6D14-T) - MITSUBISHI DIESEL ENGINE - K907 & MD180LC (1/87-12/06) (05-002) - EMERGENCY PARTS Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
698 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME049145 | [1] | SOLENOID | KOBSOLENOID,STOP 24V ND |
| 2. | VAMF140021 | [4] | SCREW | KOBBOLT,FLANGE 8X12 |
| 3. | VAME032806 | [1] | BRACKET,SOLENOID | |
| 4. | VAMF300841 | [4] | SCREW | KOBBOLT,W/WSR 10X20 Superseded by part number: 132461A1 |
| 5-8. | VAME008584 | [1] | ROD ASSY | |
| 5. | VAME008585 | [1] | ROD L=213 | |
| 6. | VAMF430003 | [1] | NUT | KOBNUT 5 Superseded by part number: 135143A1 |
| 6A. | VAMH004030 | [1] | NUT,LH SCREW 5 | |
| 7. | VAME023500 | [1] | JOINT,BALL | |
| 7A. | VAME023501 | [1] | JOINT,BALL LH SCREW | |
| 8. | VAMF430003 | [2] | NUT | KOBNUT 5 Superseded by part number: 135143A1 |
| . . | VAMF450403 | [2] | WASHER WASHER,SPG 5 | WASHER WASHER,SPG 5 |
| 8A. | VAMF450003 | [2] | WASHER PLAIN WASHER,PLAIN 5 | WASHER PLAIN WASHER,PLAIN 5 |
| 13A. | VAMH021013 | [1] | CLAMP CLAMP | CLAMP CLAMP |
| 20. | VAMS616003 | [1] | PIPE,VINYL L = 400 | |
| 21. | VAMH021104 | [1] | CLAMP, HOSE | |
