纽荷兰零件查询(F3DFA613B E004) - ENGINE 504384986 - 84550912 W/O BRAKE (10.101.01) - CYLINDER HEAD & RELATED PARTS (504386655 - 504386675 - 504386660) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
420 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 504369879 | [1] | ASSY Contains Ref.1A, 22, 23, 24, 25, 26, 27 | CYLINDER HEAD |
| 1A. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 2. | 16747024 | [1] | STUD | LEC |
| 3. | 504338164 | [1] | | CYLINDER HEAD GASKET |
| 4. | 10839710 | [2] | DOWEL,M10 x 15.00mm | TTF |
| 5. | 504108192 | [20] | SCREW,Flng, M18 x 2 x 196mm | TOR |
| 5. | 98495528 | [6] | SCREW,Shldr, Hex Flg, M18 x 2 x 175mm | TOR |
| 6. | 504109243 | [12] | | BRIDGE |
| 7. | 504138062 | [1] | PLUG | TOR |
| 7. | 504051237 | [1] | PLUG | TOR |
| 8. | 14196370 | [48] | ROCKER ARM COTTER | TOR |
| 9. | 98473050 | [24] | COTTERS PLATE | TOR |
| 10. | 504344694 | [23] | PLUG,M25, Tapered | TOR |
| 11. | 504138060 | [1] | PLUG | TOR |
| 12. | 504110997 | [24] | | VALVE SPRING |
| 13. | 504182706 | [1] | PLUG | TOR |
| 14. | 16991370 | [2] | PLUG | TOR Superseded by part number: 14282970 |
| 15. | 16990870 | [4] | PLUG | TOR Superseded by part number: 14282470 |
| 16. | 16991170 | [6] | PLUG | LEC |
| 17. | 17255674 | [1] | ROLL PIN | TOR |
| 18. | 504367479 | [24] | | PACKING RING |
| 19. | 500355778 | [12] | STD INLET VALVE | TORSTD ENGINE INLET VALVE |
| 20. | 504375458 | [12] | STD ENGINE EXHAUST VALVE | STD EXHAUST VALVE |
| 21. | 504107641 | [24] | CUP | AST |
| 22. | 504078222 | [6] | BUSHING | TOR |
| 23. | 504078223 | [1] | BUSHING | TOR |
| 24. | 504375602 | [12] | INTAKE STD. | VALVE GUIDE |
| 24. | 5801435664 | [12] | INTAKE +0,20 | VALVE GUIDE |
| 24. | 5801435665 | [12] | INTAKE +0,40 | VALVE GUIDE |
| 25. | 504375600 | [12] | EXHAUST STD. | VALVE GUIDE |
| 25. | 5801435666 | [12] | EXHAUST +0,20 | VALVE GUIDE |
| 25. | 5801435667 | [12] | EXHAUST +0,40 | VALVE GUIDE |
| 26. | 504362587 | [12] | INTAKE STD. | VALVE SEAT |
| 26. | 5801435660 | [12] | INTAKE +0,20 | VALVE SEAT |
| 27. | 504362588 | [12] | EXHAUST STD. | VALVE SEAT |
