纽荷兰零件查询(F3DFA613B E004) - ENGINE 504384986 - 84550912 W/O BRAKE (10.103.04[01]) - DAMPER - PULLEY (504386685) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
1006 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 16708634 | [2] | ASSY | SCREW |
| 2. | 504079721 | [1] | PULLEY | TOR Superseded by part number: |
| 3. | 504104314 | [1] | PULLEY | TOR |
| 4. | 504380538 | [1] | | BRACKET |
| 5. | 504380539 | [1] | | BELT |
| 6. | 504078064 | [1] | BELT TENSIONER | TOR |
| 7. | 504077389 | [1] | WASHER | TOR |
| 8. | 504079738 | [1] | SPACER | TOR |
| 9. | 504079727 | [1] | STUD | TOR |
| 10. | 16711235 | [5] | BOLT,M10 x 1.25 x 70mm | TORM12 x 1.75, 70 mm Long |
| 11. | 16676635 | [1] | BOLT | TORM10X1,5X60 |
| 12. | 16750335 | [1] | NUT | TORM10 |
| 13. | 504078065 | [2] | IDLER | TOR |
| 14. | 16680935 | [6] | SCREW,M14 x 70mm | TORM14 x 70 |
| 15. | 504381975 | [1] | | BRACKET |
